A.Y. McDonald Ranger X 5196--00 3/4" FNPT-NL Lead-Free Adapter

The A.Y. McDonald Ranger X 3/4" FNPT-NL Adapter (5196--00, manufacturer part number 74754-11) is engineered to transition Ranger X push-fit or pipe connections to a 3/4" female national pipe thread (FNPT) connection point, giving installers a fast, reliable way to tie into threaded fittings, valves, meters, and fixtures. Built as part of the trusted Ranger X product line from A.Y. McDonald, this adapter is manufactured to a no-lead (NL) specification, making it suitable for potable water applications where lead-free compliance is required. The 3/4" trade size sizing matches common residential and light commercial water service lines, and the FNPT thread profile allows the adapter to mate directly with standard male-threaded pipe, fittings, and equipment without the need for additional bushings or reducers. Whether used in new construction or repair and replacement work, this single-piece adapter reduces the number of fittings needed to complete a threaded transition, saving installation time while maintaining a leak-resistant connection point.

Key Features

  • Trade Size: 3/4" sizing for standard residential and light commercial water line connections.
  • Connection Type: Female National Pipe Thread (FNPT) end allows direct mating to male-threaded pipe, valves, and fixtures without additional bushings or reducers.
  • Ranger X Series: Part of the A.Y. McDonald Ranger X family of fittings designed for dependable, leak-resistant water service connections.
  • Lead-Free Compliance (NL): Manufactured to a no-lead (NL) specification for use in potable water systems requiring lead-free materials.
  • Adapter Configuration: Provides a simple, single-piece transition point between the Ranger X connection system and standard threaded pipe or components, reducing the number of fittings needed in an installation.
  • Manufacturer Part Number: Identified in manufacturer documentation as 74754-11, corresponding to the 3/4" FNPT-NL Ranger X adapter configuration.

Certifications & Compliance

  • Lead-Free (NL) Material Specification

Technical Specifications

  • Trade Size: 3/4"
  • Connection: FNPT-NL
  • Series: Ranger X
  • Manufacturer Part Number: 74754-11

Typical Applications

  • Residential and Light Commercial Water Service Connections
  • Potable Water Distribution Systems
  • Transitioning Ranger X Fittings to Threaded Pipe, Valves, or Fixtures
  • Water Meter and Service Line Installations
  • New Construction and Repair/Replacement Plumbing Work

Why A.Y. McDonald?

A.Y. McDonald's Ranger X line is designed to deliver dependable, code-compliant connections for water service professionals, and this 3/4" FNPT-NL adapter continues that standard with a lead-free construction suitable for potable water use. Choosing a purpose-built A.Y. McDonald adapter helps ensure a secure, leak-resistant transition between Ranger X components and standard threaded pipe, supporting reliable performance in both new installations and repair work. With the manufacturer part number 74754-11 clearly documented, professionals can confidently match this adapter to their Ranger X system requirements and specify it with certainty for lead-free potable water applications.

Manufacturer Resources

Product Specs

Product Subgroup:
Pipe Fittings
Product Group:
Plumbing
Department:
Plumbing
Product Type:
Adapter

A.Y. McDonald 5196-001 – Frequently Asked Questions

1) Is the A.Y. McDonald 5196 Ranger X adapter lead free for potable water?
Yes, it is a no-lead (NL) adapter, which is what the NL suffix in the Ranger X FNPT-NL designation denotes. That is the version specified for potable water service lines.
2) What kind of connection is on the A.Y. McDonald Ranger X adapter?
One end is female NPT (FNPT) tapered pipe thread, so it threads onto male NPT pipe or a male-threaded fitting. The other end is the Ranger X connection, so it is used to transition a Ranger X service fitting over to standard threaded pipe.
3) Will the 3/4 inch Ranger X adapter thread onto 3/4 inch galvanized or brass pipe?
It will. The 3/4 inch version (5196-001) has a 3/4 inch female NPT port, and NPT is the same tapered thread used on schedule galvanized steel and brass nipples, so it mates with any 3/4 inch male NPT pipe end regardless of pipe material. Use thread sealant rated for potable water.
4) I need to go from a Ranger X service fitting to a threaded meter setter or valve. Is this the right part?
That is exactly what the 5196 adapter is for: it converts the Ranger X connection to a female NPT port so you can thread in a male-NPT valve, nipple, or setter tail. If the mating component is female threaded instead, you will need a male nipple between the two.
5) Can I use the 1 inch Ranger X adapter on a 3/4 inch service line?
Not directly. The 1 inch adapter (5196-004) has a 1 inch FNPT port and a 1 inch Ranger X end, so on a 3/4 inch line you would either order the 3/4 inch adapter (5196-001) or add a 1 inch by 3/4 inch bushing, which adds a joint you may not want buried.
