ABB TGRK R-Fuse Safety Switch Fuse Kit, NEMA 1/3R

ABB TGRK R-Fuse Safety Switch Fuse Kit, NEMA 1/3R

(No reviews yet) Write a Review

Model: TGRK22

In Stock (leaves warehouse same day if ordered before 3pm ET)

$58.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABB TGRK R-Fuse Safety Switch Fuse Kit, NEMA 1/3R

The ABB TGRK R-Fuse Safety Switch Fuse Kit is a replacement fuse kit engineered for ABB Spec-Setter safety switches, delivering the rugged, reliable performance ABB is known for across commercial and industrial electrical systems. This fuse kit is rated 240V AC and housed to NEMA Type 1/3R enclosure standards, making it suitable for both indoor panels and outdoor, wet-location service equipment. It is available in amperage options ranging from 30A through 200A, so electrical professionals can match the correct fuse kit to the specific ABB Spec-Setter safety switch platform they are servicing — from general-duty switches for light commercial work to heavy-duty switches for demanding industrial environments. Choosing the correct amperage option keeps safety switch installations code-compliant and ready for service.

Key Features

  • Amperage Options: Available in 30A, 60A, and 200A ratings to match the specific ABB safety switch fuse holder being serviced.
  • Enclosure Rating: NEMA Type 1/3R construction supports both indoor and outdoor, wet-location safety switch installations.
  • Voltage Rating: Rated 240V AC across all amperage options for use with compatible ABB safety switch fuse holders.
  • R-Fuse Design: Purpose-built replacement fuse kit for ABB Spec-Setter safety switches, ensuring proper fit and reliable electrical continuity.
  • Application Versatility: Suited to general-duty and heavy-duty safety switch platforms used across residential, light commercial, and industrial settings.
  • Rugged Build: Reflects ABB's Spec-Setter design philosophy — easy to install and built to hold up in demanding electrical environments, including cement foundries, steel mills, and processing plants.
  • Packaging: Supplied as 1 EA per amperage option for straightforward stocking and replacement on hand.

Certifications & Compliance

  • NEMA Type 1/3R Enclosure Rated

Technical Specifications

  • Enclosure: NEMA Type 1 / 3R
  • Voltage Rating: 240V AC
  • Amperage Options: 30A, 60A, 200A
  • Configuration: NEMA 1/3R Enclosure

Typical Applications

  • Commercial and Industrial Electrical Installations
  • Safety Switch Fuse Replacement and Maintenance
  • Heavy-Duty Industrial Environments Such as Foundries, Steel Mills, and Processing Plants
  • Emergency Generator Double-Throw Switch Systems
  • Indoor and Outdoor Electrical Service Equipment
  • General Duty Panels in Residential and Light Commercial Settings

Why ABB?

ABB backs its Spec-Setter safety switch line with rugged, reliable components like this R-Fuse Kit, engineered for easy installation and dependable performance across general-duty and heavy-duty applications. Offered in 30A, 60A, and 200A options, all rated 240V AC with NEMA Type 1/3R enclosure compatibility, this fuse kit supports code-compliant electrical service in environments ranging from light commercial buildings to the toughest industrial facilities. Electrical professionals can rely on ABB's Spec-Setter engineering to select the correct amperage and install a dependable replacement part with confidence.

Manufacturer Resources

Product Specs

Product Type:
Fuse Kit
Voltage Rating:
240V
Configuration:
NEMA 1/3R Enclosure
Series:
R-Fuse
Department:
Electrical
Product Group:
Wiring Devices
Amperage Rating:
30A - 200A
Product Subgroup:
Parts & Accessories

ABB TGRK22 – Frequently Asked Questions

1) What amperage ratings does the ABB R-Fuse safety switch fuse kit come in?
Three amp ratings are offered: 30 amp (TGRK12), 60 amp (TGRK22), and 200 amp (TGRK42). Match the kit to the amp rating of the Spec-Setter safety switch you are servicing, not to the load, since the fuse holder hardware is sized to the switch frame.
2) Will the ABB TGRK fuse kit work on a 480V safety switch?
No. The R-Fuse kit is rated 240V AC, so it belongs on 240V class safety switches only. For a 480V switch you need a kit rated for that class of service.
3) Can this ABB fuse kit be used in an outdoor safety switch?
Yes. The R-Fuse kit is built to NEMA Type 1/3R enclosure standards, which covers indoor panels and outdoor, rain-exposed service equipment. That makes it usable on exterior disconnects at rooftop units, pumps, and generator gear as well as interior panel rooms.
4) Which ABB safety switches does the TGRK fuse kit fit?
It is built specifically for ABB Spec-Setter safety switches, covering both the general-duty switches used in residential and light commercial panels and the heavy-duty switches used in industrial plants. It is not a universal kit for other brands of disconnect.
5) What exactly is an R-Fuse kit for a safety switch, and do I get fuses with it?
An R-Fuse kit is the rejection hardware that fits into the fuse clips of an ABB Spec-Setter safety switch so the switch will only accept Class R fuses. It is ordered as a replacement or field-conversion kit, supplied 1 EA, and is specified by the switch's amp rating: 30, 60, or 200 amp.
6) I have a 60 amp ABB disconnect on an emergency generator transfer setup. Which part number do I order?
TGRK22 is the 60 amp version of the R-Fuse kit. The line is called out for emergency generator double-throw switch systems, and at 240V AC it suits typical 240V generator service gear.
7) Is the ABB R-Fuse kit suitable for a foundry or steel mill disconnect?
Yes. The Spec-Setter platform it supports is called out for demanding industrial service including cement foundries, steel mills, and processing plants, and the NEMA 1/3R rating handles washdown-adjacent and outdoor locations. Keep the voltage in check, though: the kit is a 240V AC part.
8) How many kits do I need for a three-phase safety switch?
Each order is supplied as 1 EA, so plan quantity around how many fuse positions your switch carries and stock spares accordingly. Amp rating must match the switch frame: 30 amp TGRK12, 60 amp TGRK22, or 200 amp TGRK42.
