ABB THQB Bolt-On Circuit Break...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$334.64
ABB THQB Bolt-On Circuit Breaker, 120/240V

ABB THQB Bolt-On Circuit Breaker, 120/240V

(No reviews yet) Write a Review

Model: THQB1120ST1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$334.64
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABB THQB Bolt-On Circuit Breaker, 20A 1-Pole 120/240V HID

The ABB THQB is a bolt-on Q Line circuit breaker built for residential and commercial panelboards and lighting panels. This compact, one-inch-wide-per-pole thermal-magnetic device is rated 20A, 1-pole, 120/240V, with a 10kA interrupt rating, and is configured for HID (high intensity discharge) lighting applications. Like all Q Line breakers, the THQB bolts directly to the bus connections of a load center or lighting panel and combines a Quick-make / Quick-break mechanism with a common trip bar and easy-to-spot trip indication for dependable, code-compliant circuit protection. The THQB is part of the broader Q Line family, which is available in 1, 2, and 3-pole versions and can be ordered with auxiliary contact or shunt trip accessories, giving electricians flexibility when specifying panel protection for HID lighting circuits.

Key Features

  • Amperage Rating: 20A rating configured for HID (high intensity discharge) lighting loads.
  • Poles: 1-pole configuration with a common trip bar for reliable circuit isolation.
  • Voltage Rating: Rated for 120/240V residential and commercial distribution systems.
  • Interrupt Rating: 10kA interrupt capacity for dependable fault protection.
  • Bolt-On Mounting: Bolts directly to the bus connections of Q Line load centers and lighting panels.
  • Quick-Make / Quick-Break Mechanism: Fast-acting operation for improved safety during switching and fault clearing.
  • Trip Indication: Easy-to-spot trip indicator lets electricians quickly identify a tripped breaker.
  • Compact Design: One-inch wide per pole for space-efficient panel layouts.
  • Family Flexibility: Part of the Q Line series, available in 1, 2, and 3-pole versions with optional auxiliary contact and shunt trip accessories.

Technical Specifications

  • Country of Origin: UKN
  • Packaging: 1 EA

Typical Applications

  • Residential and Commercial Panelboards and Load Centers
  • Lighting Panel Circuit Protection
  • HID (High Intensity Discharge) Lighting Circuits
  • Bolt-On Bus Connection Retrofits and Replacements
  • Renovation and New Construction Electrical Distribution

Why ABB?

The ABB THQB Q Line circuit breaker delivers the bolt-on reliability, Quick-make / Quick-break switching, and clear trip indication that electrical professionals depend on for safe, code-compliant panel protection. Its compact thermal-magnetic design and 10kA interrupt rating make it a dependable choice for 120/240V residential and commercial circuits, including dedicated HID lighting loads. For contractors and facility teams standardizing on Q Line panels, the THQB offers a straightforward bolt-on replacement or new-install option that matches the fit, function, and safety features of the wider ABB Q Line breaker lineup.

Manufacturer Resources

Spec Sheet

Product Specs

Product Group:
Circuit Protection
Product Type:
Circuit Breaker
Voltage Rating:
120/240V
Configuration:
1-Pole
Department:
Electrical
Product Subgroup:
Circuit Breakers

ABB THQB1120ST1 – Frequently Asked Questions

1) Will an ABB THQB breaker fit a plug-on load center, or does the panel have to be bolt-on?
The THQB is a bolt-on Q Line breaker. It fastens directly to the bus connections of a Q Line load center or lighting panel, so the panel interior has to be drilled and tapped for bolt-on mounting. If your panel takes plug-on breakers that clip onto the bus stab, a THQB will not seat in it. Check the panel label for bolt-on Q Line acceptance before ordering.
2) What amperages and pole counts can I get in the ABB THQB line?
1-pole THQB runs 15A, 20A, 25A, 30A and 60A. The 2-pole covers 15, 20, 25, 30, 40, 45, 50, 60, 70, 80, 90 and 100A. The 3-pole covers 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90 and 100A. Part numbers follow the pattern: THQB1120 is 20A 1-pole, THQB2150 is 50A 2-pole, THQB32060 is 60A 3-pole.
3) Is there an ABB THQB breaker made specifically for HID lighting circuits?
Yes, THQB1120HID is the 20A 1-pole version configured for high intensity discharge lighting loads. HID ballasts draw a long inrush at startup, and the HID-rated unit is the one to specify for metal halide or high pressure sodium lighting panels. A standard THQB1120 is the same amperage but is not the HID configuration.
4) Can I get a THQB with shunt trip for a fire alarm or elevator disconnect?
Shunt trip is available as a factory configuration, not something you add in the field on these. THQB1120ST1 is the 20A 1-pole shunt trip and THQB32030ST1 is the 30A 3-pole shunt trip. The Q Line family also supports auxiliary contact accessories. If your elevator or kitchen hood shutdown scheme needs remote tripping, order the ST version rather than a standard breaker.
5) Does ABB make an arc fault version of the THQB for bedroom and living area circuits?
THQB1120AF2 is the 20A 1-pole arc fault version. That is the one to use where the NEC requires AFCI protection on 120V branch circuits. The plain THQB1120 is thermal-magnetic only with no arc fault sensing.
6) Can a Square D Multi9 C60 breaker be used in place of an ABB THQB in a Q Line load center?
No. The THQB is a bolt-on breaker that fastens directly to the bus connections of a Q Line load center or lighting panel, one inch wide per pole. The Square D Multi9 C60 is a miniature circuit breaker built for DIN rail mounting, so it has no bus stab or bolt-on interface and needs a DIN rail enclosure instead of a panelboard bus. Use the C60 family where the design calls for DIN rail control or distribution gear, and the THQB where a Q Line panel bus is being fed.
7) What should I use instead of a THQB if the panel is an I-Line panelboard?
The ABB THQB is built for Q Line load centers and lighting panels and bolts to that bus, so it will not land in an I-Line panelboard. For I-Line gear the Square D PowerPacT Q I-Line circuit breaker is the family designed for that bus connection. Keep the THQB for Q Line 120/240V residential and commercial distribution.
8) How many breaker spaces does a 2-pole or 3-pole THQB take up in the panel?
Q Line THQB breakers are one inch wide per pole. A 1-pole takes one space, a 2-pole takes two, and a 3-pole takes three adjacent spaces. Multi-pole versions use a common trip bar so all poles clear together on a fault.
9) Can I use a THQB on a 208Y/120 three phase panel?
The THQB is rated 120/240V. A 3-pole THQB such as the THQB32060 is built for three phase distribution at that voltage class, and single pole units serve 120V line-to-neutral circuits. For 480V or 277/480V systems this is the wrong breaker family entirely.
10) What else could I use if my panel is DIN rail rather than a Q Line load center?
The THQB will not work on DIN rail, it is a bolt-on bus-mounted breaker. For DIN rail applications look at the Square D C60 UL489 miniature circuit breaker, which is built for DIN rail mounting, or the Square D Multi9 C60 1-pole C-curve MCB for 120V AC control and lighting circuits.
11) I need a molded case breaker for a feeder, not a branch circuit. What should I look at instead of a THQB?
THQB tops out at 100A in 2 and 3-pole and is a panelboard branch and small feeder device. For larger molded case feeder duty, the Square D PowerPacT B thermal magnetic breaker is the comparable option, and the PowerPacT Q I-Line breaker is the choice where the panel is an I-Line bus rather than a Q Line load center.
12) How does the ABB THQB differ from a Square D PowerPacT B breaker?
Both are thermal-magnetic devices. The THQB is a plug-and-bolt Q Line branch breaker, one inch wide per pole, rated 120/240V with a 10kA interrupt rating and available in 1, 2, and 3-pole versions from 15A through 100A. The Square D PowerPacT B is a molded case thermal magnetic breaker in its own frame, typically applied as a main or feeder device rather than a Q Line panel branch breaker. Choose by what the panel bus accepts and whether the circuit is a branch or a feeder.
13) For a 3-pole 480V circuit, is the THQB the right breaker?
No. The ABB THQB is rated 120/240V, including its 3-pole versions from 15A to 100A, so it does not cover higher-voltage three-phase distribution. For that duty look to a molded case family such as the Square D PowerPacT B thermal magnetic breaker or the PowerPacT Q I-Line breaker, chosen to match the panel and system voltage. Keep the THQB on 120/240V Q Line panels.
14) How do I tell which breaker tripped in a THQB panel?
Q Line THQB breakers have a trip indicator, so a tripped pole sits visibly between on and off rather than looking like someone switched it off. Combined with the Quick-make / Quick-break mechanism, that lets a facility tech identify and reset the faulted circuit without meter work.
15) Are THQB breakers sold individually or in multi-packs?
THQB breakers are packaged one each, so quantity ordered equals breakers received. Useful when you are filling a panel schedule and need an exact count of 15A and 20A single poles.
