ABH CME0340 Electrified Top Pi...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$943.00
$926.66
ABH ABH CME0340 Electrified Top Pivot - Center Hung - Heavy Duty ABH-CME0340

ABH CME0340 Electrified Top Pivot - Center Hung Heavy Duty with Concealed Magnetic Monitor

(No reviews yet) Write a Review

Model: CME0340-US26
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$943.00
$926.66
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH CME0340 Electrified Top Pivot - Center Hung Heavy Duty with Concealed Magnetic Monitor

Professional Electrified Pivot Solution for Heavy-Duty Commercial Applications

The ABH CME0340 Electrified Top Pivot delivers professional-grade performance for center hung door installations requiring electronic monitoring capabilities. This heavy-duty pivot features a concealed magnetic monitor switch with thru wires included, supporting doors up to 300 lbs. Constructed from stainless steel with a walking beam design, this non-handed pivot provides reliable operation for demanding commercial applications where electronic door position monitoring is essential.

Professional Features & Benefits

  • Heavy-Duty Load Capacity: Supports doors up to 300 lbs for robust commercial door installations requiring substantial weight handling.
  • Concealed Magnetic Monitor Switch: Integrated electronic monitoring with thru wires included provides door position feedback for access control and security systems.
  • Walking Beam Top Pivot Design: Engineered for center hung bottom pivot or floor closer configurations ensuring proper door alignment and smooth operation.
  • Stainless Steel Construction: Durable stainless steel substrate provides exceptional corrosion resistance and long-term reliability in commercial environments.
  • Non-Handed Installation: Universal design eliminates handing requirements for simplified inventory management and installation flexibility.
  • Professional Mounting System: Jamb leaf mortises in header and door leaf mortises into top of door with dress plate provided for clean, professional appearance.
  • BAA Qualified: Meets Buy American Act requirements for government and institutional projects requiring domestic sourcing compliance.

Technical Specifications

  • Application: Concealed, Electrified
  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Weight: Up to 300 lbs
  • Duty Level: Heavy Duty
  • Electronic: Yes
  • Fire Rating: No
  • Hang Type: Offset Hung
  • Keyed: N/A
  • Keyed Function: N/A
  • Mounting Method: Center Hung
  • PDF: CME0340 Top Pivot Center Hung - Electrified - Template: https://zensupply.com/content/pdf/abh/0000393_cme0340_01_102620.pdf
  • PDF: EZ Connect Wire Color & Position Diagram Micro-Fit 3.0: https://zensupply.com/content/pdf/abh/0000157_ez_connect_wire_color_and_position_diagram_micro_fit_30.pdf
  • PDF: Pivot Configuration for Center Hung Pivot Sets: https://zensupply.com/content/pdf/abh/0002298_pivot_configurations_0127012803700327.pdf
  • PDF: Pivot Set Configurations: https://zensupply.com/content/pdf/abh/0002621_pivot_set_configurations.pdf
  • PDF: Pivot Type Center Hung: https://zensupply.com/content/pdf/abh/0000164_tm_pivot_type_center_hungl.pdf
  • PDF: Pivot and Pivot Sets Special Layout Order Form - Must Download: https://zensupply.com/content/pdf/abh/0002519_pivot_and_pivot_sets_special_layout_form_1.pdf
  • PDF: Pivots Cross Reference Chart: https://zensupply.com/content/pdf/abh/0000411_cross_reference_chart.pdf
  • PDF: Substitution Request Pivots: https://zensupply.com/content/pdf/abh/0000116_substitution_request_form_compressed.pdf
  • Pivot Type: Intermediate
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: 180
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Stainless Steel
  • Product Type: Pivot Sets - Offset
  • Subcategory: Door Pivots

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Access Control Integration Projects

Why Choose ABH Quality?

ABH electrified pivot products deliver professional-grade reliability with stainless steel construction rated for doors up to 300 lbs. BAA qualified for government projects with concealed magnetic monitoring capabilities for advanced access control integration. Engineered for demanding commercial applications where dependable electronic door hardware performance is essential.

Product Specs

Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Pivot Sets - Offset
Subcategory:
Door Pivots
Commercial/Residential:
Commercial
Hang Type:
Offset Hung
Keyed:
N/A
Keyed Function:
N/A
Door Weight:
Up to 300 lbs
BAA Qualified:
Yes
Duty Level:
Heavy Duty
Electronic:
Yes
Pivot Type:
Intermediate
Mounting Method:
Center Hung
Application:
Concealed, Electrified
Product Attribute:
Pivots
Product Model:
180
Fire Rating:
No
Product Category:
Door Hinges and Pivots
Product Substrate:
Stainless Steel
Department:
Door Hardware

ABH CME0340-US26 – Frequently Asked Questions

1) What does the ABH CME0340 top pivot actually do, and do I still need a bottom pivot or floor closer?
The CME0340 is a walking beam top pivot only, built for center hung openings. It carries the head of the door and adds a concealed magnetic monitor switch with thru wires so the door position reports back to an access control or alarm panel. The load is carried at the bottom, so you still need a center hung bottom pivot or a floor closer under the door. Order that separately.
2) Can I use the CME0340 electrified pivot on a fire rated door?
No. The CME0340 pivot is not fire rated, so it cannot go on a labeled fire door assembly. For a rated opening you need pivot hardware carrying a fire rating, such as the BEST A3 System offset hung pivot set, which is fire rated.
3) How does the CME0340 mortise into the door and frame?
Two mortises. The jamb leaf mortises into the header, and the door leaf mortises into the top edge of the door. A dress plate comes with it to cover the door leaf prep. Because the switch and wiring are concealed inside those mortises, this is a prep-in-advance part: get the template into the door shop before the leaf is finished rather than trying to route it in the field.
4) Do I need a separate door position switch if I install the ABH CME0340?
No. The monitor switch is built into the pivot, so you skip the surface or recessed DPS in the frame entirely. Thru wires are included to get the contact out of the pivot. For integrators, that is one less hole in the header and one less exposed device on a high-traffic entrance. Wire color and pin position for the Micro-Fit 3.0 EZ Connect side are documented in ABH's wire diagram sheet.
5) What pivot works instead of the ABH CME0340 on a fire rated opening?
The ABH CME0340 electrified top pivot is not fire rated, so on an opening that has to carry a fire label, look at the BEST A3 System offset hung pivot set, which is fire rated. The tradeoff is function: the CME0340 carries a concealed magnetic monitor switch with thru wires for door position feedback, and the A3 is a mechanical pivot set with BEST premium core technology. If the opening needs both a fire label and electronic monitoring, the monitoring has to come from another device in the opening rather than from the pivot.
6) Do I have to specify handing when ordering the ABH CME0340 pivot?
No handing to call out. The CME0340 is non-handed, so one part number covers left and right hand openings, in or out swing. For a property manager or facility stocking spares, that means a single pivot on the shelf works on any of the center hung doors it fits.
7) Does the ABH CME0340 monitored pivot qualify for a Buy American Act project?
Yes, the CME0340 is BAA qualified, which is what matters on federal, GSA, and many state or municipal jobs with domestic sourcing language in the spec. Institutional buyers standardizing monitored center hung openings across a campus can carry it on a BAA-restricted package.
8) Can a full offset pivot set be ordered in place of the ABH CME0340, or is that a different part?
It is a different part, and this is the most common mix-up. The ABH CME0340 is a single top pivot in stainless steel, intended to work with a center hung bottom pivot or floor closer, and it is not a complete set. The BEST A3 System offset hung pivot set and the Calibre Door Closers PV1000 3/4 inch offset flush pivot set are each supplied as a pivot set covering the opening. Ordering a set when only the electrified top pivot is being replaced leaves parts on the shelf, and ordering the CME0340 alone for a bare opening leaves the bottom of the door unsupported.
9) For a federal or municipal job with domestic sourcing requirements, which pivot should be specified?
The ABH CME0340 electrified top pivot is BAA qualified, which is what a government or institutional specification with Buy American Act language is looking for, and it handles doors up to 300 lbs in a heavy duty commercial rating. Among the comparable offset pivots, the BEST A3 System offset hung pivot set is the one that carries a fire rating, so on a labeled opening in that same facility the A3 is the pivot to specify and the door position monitoring is handled elsewhere in the opening.
10) What finishes does the ABH CME0340 pivot come in?
Fourteen, and they split into two groups that matter for matching an existing entrance. Plated and metal finishes: bright and satin stainless steel, bright and satin brass, bright chrome, bright bronze, satin bronze, and oil rubbed bronze. Painted and coated finishes for matching storefront or aluminum framing: painted aluminum, painted brass, painted satin bronze, painted dark bronze, black suede powder coat, and white suede powder coat. If you are matching a dark bronze aluminum entrance, the painted dark bronze or black suede is the closer match than a plated bronze.
11) Is the ABH CME0340 pivot suitable for a residential door?
It is a commercial part. Rated heavy duty for doors to 300 lbs with a monitored contact for access control, it is aimed at office lobbies, schools, hospitals, government buildings, warehouses, and multi-tenant residential entrances. On a single-family interior door it is far more pivot than the opening needs and it requires a floor closer or bottom pivot underneath.
