Accentra 8800 Series Mortise Lock Thumbturn with Round Plate and Mounting Screws, 630 Satin Stainless Steel

Accentra 8800 Series Mortise Lock Thumbturn with Round Plate and Mounting Screws

(No reviews yet) Write a Review

Model: GF1824-626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$91.16
$66.89
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra 8800 Series Mortise Lock Thumbturn with Round Plate

The Accentra 8800 Series thumbturn is a cast zinc replacement and service component for 8800 Series mortise locks configured with round rose sectional trim or lock functions requiring thumbturn operation. The 1-7/8" (48mm) diameter round plate is available in brass and stainless steel base materials across multiple BHMA finishes. Mounting hardware is included.

Specifications

  • Plate Diameter: 1-7/8" (48mm)
  • Construction: Cast zinc thumbturn
  • Plate Material: Brass or stainless steel (finish-dependent)
  • Included Hardware: #6 x 3/8" AB oval Phillips head mounting screws
  • Compatible Series: Accentra 8800 Series mortise locks with round rose sectional trim
  • Application: Commercial

Compatibility

Supplied as factory standard on applicable 8800 Series lock functions. Verify the existing lock function and trim configuration before ordering a replacement. Refer to the 8800 Series installation instructions for mounting details.

Manufacturer Resources

8800 Series Mortise Locks

Product Specs

Product Type:
Thumbturns
Commercial/Residential:
Commercial
Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Category:
Cylindrical Locks
Department:
Door Hardware

Accentra GF1824-626 – Frequently Asked Questions

1) Will this Accentra thumbturn fit my 8800 Series mortise lock?
It fits 8800 Series mortise locks set up with round rose sectional trim, and lock functions that call for thumbturn operation. The plate is a 1-7/8 inch (48mm) round, so it lands on the same footprint as the round rose already on the door. Check two things on the lock you're servicing: that the trim is round rose sectional rather than a full escutcheon plate, and that the function actually uses a turn on the inside. If both are true, this is the correct service part.
2) My 8800 mortise lock has escutcheon trim, not round roses. Can I use this thumbturn?
No. The 8800 Series thumbturn with the 1-7/8 inch round plate is built for locks trimmed with round rose sectional trim, and the round plate won't match or cover an escutcheon-trimmed opening. For a lock running full escutcheon plates, order the turn piece that matches that trim style instead. Pull the existing trim and confirm which style is on the door before you order, because the two aren't interchangeable.
3) Does the Accentra 8800 thumbturn come with mounting screws, or do I need to order hardware separately?
Screws are in the box. Each thumbturn ships with #6 x 3/8 inch AB oval Phillips head mounting screws, so nothing else has to be sourced to fasten the plate. The only thing to bring to the job is the right screwdriver and the 8800 Series installation instructions for the mounting sequence.
4) What finishes does the Accentra 8800 mortise thumbturn come in so it matches my existing lever trim?
Seven BHMA finishes: 605 bright brass, 606 satin brass, 612 satin bronze, 613 oil rubbed bronze, 625 bright chrome, 626 satin chrome, and 630 satin stainless steel. Match the number stamped or specified on the rest of the trim on that opening rather than matching by eye, since 626 satin chrome and 630 satin stainless read very similarly on a door but are different finishes on different base metals.
5) My lock is a Yale 8800 mortise lock. Is this Accentra thumbturn the right replacement part?
The 8800 Series is the same commercial mortise platform that ASSA ABLOY now sells under the Accentra name, so an 8800 turn piece is specified by series and trim style, not by which brand name is on the lock face. What decides fit is the trim: round rose sectional trim and a function that uses a turn. Confirm those on the door and the 1-7/8 inch round-plate turn is the part you want.
6) How do I know whether my 8800 mortise lock is supposed to have a thumbturn at all?
Go by the lock function. The turn is factory standard on the 8800 Series functions that are built for thumbturn operation, so if the lock came from the factory with a turn on the inside rose, this is the service replacement for it. If the inside rose is blank or carries a cylinder instead, the function doesn't use a turn and adding one isn't a swap. Identify the function code on the existing lock first, then order to match it.
7) Is this thumbturn built for commercial traffic or is it a residential-grade part?
Commercial. The turn piece is cast zinc and the round plate is brass or stainless steel depending on which finish you order, and it's the service component for 8800 Series mortise locks, which are commercial mortise hardware. For a property manager standardizing across a building, the practical point is that you can keep one part number on file and order it in whatever finish each wing of the building uses.
