Accentra A620 7-Pin SFIC Mortise Cylinder

Accentra A620 7-Pin SFIC Mortise Cylinder

(No reviews yet) Write a Review

Model: A620 626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$203.00
$114.10
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra A620 7-Pin SFIC Mortise Cylinder

Accentra A620 7-Pin SFIC Mortise Cylinder

High-Quality Mortise Single Cylinder with Small Format Interchangeable Core

The Accentra A620 is a high-quality, single cylinder solution designed for durability and reliable performance within mortise locks. This robust cylinder is engineered to function with standard 1-3/4" thick doors and features a versatile small format interchangeable core (SFIC) design. The A620 is available in both 6-pin and 7-pin options, providing the flexible security system you need.

Detailed Features and Specifications

  • Cylinder Type: Single Cylinder, Door Cylinder for mortise locks.

  • Core Type: Small Format Interchangeable Core (SFIC).

  • Pin Count: Available in 7-Pin and 6-Pin options.

  • Keys Included: This uncombinated cylinder is supplied with two master keys and one control key.

    • Control Key Function: The control key is only used to install and remove cores and does not operate the lock.

  • Keying Options: Can be master keyed, grand master keyed, and great grand master keyed. Core must be master keyed or factory keyed.

  • Supported Keyways: The A620 can be ordered with most common SFIC keyways, including A, B, C, D, DD, E, F, G, H, J, K, L, M, Q, 1C, 1D, to match your existing system.

  • Finishes: Available in multiple finishes to coordinate with your hardware.

Manufacturer Resources

Cylinders and Keying Catalog

Product Specs

Product Type:
Cylinder Housing
Commercial/Residential:
Commercial
Product Group:
Parts and Accessories
Product Subgroup:
Cylinders
Product Category:
Cylindrical Locks
Department:
Door Hardware

Accentra A620 626 – Frequently Asked Questions

1) Will the Accentra A620 mortise cylinder work in my mortise lock on a 1-3/4 inch door?
Yes. The A620 is a single mortise cylinder built to work in mortise locks on standard 1-3/4 inch thick doors, which is the normal commercial door thickness. It is the cylinder housing plus core, not the lock body itself, so the mortise lock case has to already be prepped for a threaded mortise cylinder.
2) Can I order the Accentra A620 SFIC cylinder in my building's existing keyway?
Most likely. The A620 can be ordered in most common small format interchangeable core keyways: A, B, C, D, DD, E, F, G, H, J, K, L, M, Q, 1C and 1D. Match the letter stamped on your existing cores or keys and the new cylinder drops into the same key system.
3) Does the Accentra A620 come keyed, or do I have to have it combinated?
It ships uncombinated. The core has to be master keyed or factory keyed before it will operate, so plan on either specifying factory keying at order time or having your locksmith pin it to your system. Two master keys and one control key come with it.
4) What does the control key that comes with the A620 cylinder actually do?
The control key only pulls and installs the interchangeable core. It will not throw the lock. That is the point of small format IC: when a tenant turns over or a key goes missing, you pull the core with the control key and drop a new one in without taking the mortise lock apart or touching the door. Keep the control key separate from the operating keys, because whoever holds it can remove cores across the whole system.
5) Should I buy the 7-pin or the 6-pin version of the Accentra A620?
Match whatever your existing system uses, because 6-pin and 7-pin SFIC cores are not interchangeable within one key system. The A620 is offered both ways. If you are starting fresh and want room to expand master keying levels later, 7-pin gives you more depth; if the rest of the property is already 6-pin, stay 6-pin.
6) Can I use the A620 to replace a keyed cylinder in a mortise lock without changing the lock?
That is exactly what it is for. The A620 is a cylinder housing for a mortise lock case, so you back out the existing mortise cylinder and thread this one in, leaving the lock body, trim and door prep alone. What you do need to confirm is that the mortise lock accepts an SFIC cylinder and that the cam matches the lock function you are driving.
7) The building is keyed on large format interchangeable cores - what mortise housing works instead of the Accentra A620?
Use the Kaba Ilco S26506, a mortise large format IC core convertible housing in the Schlage size. The Accentra A620 is built for small format interchangeable cores, so a large format core will not seat in it no matter the keyway. If the cores coming off the doors are the larger figure-eight style rather than the small format core, the S26506 is the mortise housing to match, and its Schlage size is the detail to confirm against the cores already in the facility.
8) What else takes a small format interchangeable core if the Accentra A620 does not fit the keying system?
The Kaba Ilco R2800 Series is a small format IC core convertible housing, so it accepts the same small format interchangeable core the A620 is built around. The A620 is a single mortise cylinder for small format interchangeable cores that can be ordered in most common SFIC keyways including A, B, C, D, DD, E, F, G, H, J, K, L, M, Q, 1C and 1D, and it is supplied uncombinated with two master keys and one control key, with the control key used only to install and remove cores. The R2800 is described as convertible, which is the difference worth confirming against the core you already stock before you order either one.
9) Can the A620 be master keyed and grand master keyed for a large property?
Yes, it supports master keying, grand master keying, and great grand master keying, so it can sit anywhere in a multi-level hierarchy across a portfolio of buildings. That is what makes it workable for a property manager or facility standardizing several doors on one key system.
10) What else could I use if I need a small format IC housing but not the Accentra one?
The Kaba Ilco R2800 Series is a small format IC core convertible housing and is the cross-brand option to look at. Because SFIC cores are a common format, a core keyed to your system will seat in either brand's housing as long as the keyway and pin count match. Where the A620 differs is that it is supplied as an Accentra mortise cylinder with two master keys and a control key included.
11) Is the Kaba Ilco S26506 a drop-in substitute for the Accentra A620 mortise cylinder?
No. Both are mortise cylinder housings, which is why they read as interchangeable, but they take different core families: the S26506 is a large format IC core housing in the Schlage size, while the A620 is a small format interchangeable core cylinder. Ordering the S26506 against an A620 line leaves you with a housing your small format cores will not drop into. For a small format core system, the Kaba Ilco R2800 Series small format IC core convertible housing is the one to cross-check.
12) What finish does the Accentra A620 mortise cylinder come in?
Satin chrome, finish 626. That is the standard commercial finish and it coordinates with the great majority of Grade 1 lever and mortise trim already hanging in office and institutional buildings, so it will not stand out against existing hardware.
13) Is the Accentra A620 a residential or commercial cylinder?
Commercial. The A620 is an interchangeable-core mortise cylinder aimed at institutional and commercial key systems, where cores get rotated on turnover and keying is administered centrally, rather than at a single-home application.
