Alarm Lock Trilogy Networx AL-IME2 Generation 2 Wireless Gateway with Ethernet Interface

Alarm Lock Trilogy Networx AL-IME2 Generation 2 Wireless Gateway with Ethernet Interface

Professional Network Integration Solution for Networx Lock Systems

The Alarm Lock Trilogy Networx AL-IME2 Generation 2 Gateway provides seamless network integration for Networx lock systems through hardwired Ethernet connectivity. This advanced gateway supports up to seven AL-IME2-EXP Expanders, with each expander extending coverage by approximately 100 feet. Operating on 900 MHz GFSK with 50 channels and 10 mW power output, the system delivers reliable wireless communication with clear field range of 500 feet and typical indoor range of 75-175 feet for Networx locks.

Professional Features & Benefits

• Extended Network Coverage: Supports up to seven AL-IME2-EXP Expanders with each unit extending range by approximately 100 feet for comprehensive facility coverage.
• Dual Network Interface: Ethernet 10Base-T or 100Base-TX connectivity using RJ45 jack with TCP/IP, UDP/IP, and DHCP protocol support for flexible network integration.
• Advanced Wireless Technology: 900 MHz GFSK radio with 50 channels and 10 mW power output provides reliable communication with 500-foot clear field range.
• Flexible Power Requirements: 5-6 volts AC input with 650 mA peak supply current for efficient operation in various electrical configurations.
• Wide Operating Range: Functions reliably in temperatures from -20° to 60°C (-4° to 140°F) with storage capability from -40° to 85°C (-40° to 185°F).
• Comprehensive Software Support: Compatible with Trilogy Networx DL-WINDOWS software for centralized programming and database management, plus optional Lenel OnGuard or Continental CardAccess integration.
• Compact Professional Design: Modern styling with three LED indicators in a 4.5"H x 6.0"W x 1.94"D enclosure weighing 0.5 pounds blends seamlessly into any environment.
• Enhanced Generation 2 Features: Improved extended potential range and modern styling compared to original hardwired Gateway Modules for superior performance.

Technical Specifications

• Product Category: Parts and Accessories
• Product Group: Parts and Accessories
• Product Type: Gateway
• Subcategory: Accessories

Installation & Operation

1. Verify electrical requirements match available power supply. Confirm 5-6 volts AC input and 650 mA peak current capacity before proceeding.
2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
4. Route and connect wiring according to manufacturer wiring diagrams. Connect Ethernet cable to RJ45 jack and configure network settings for TCP/IP, UDP/IP, or DHCP as required.
5. Configure operational settings including network protocols and expander connections per application requirements.
6. Restore power and test all functions including network connectivity, wireless communication range, and integration with connected Networx lock systems.
7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

• Commercial Building Access Control Systems
• Educational Institution Security Networks
• Healthcare Facility Access Management
• Multi-Tenant Residential Properties
• Industrial Facility Security Integration
• Government and Municipal Building Networks
• Enterprise Real-Time Processing Solutions

Why Choose Alarm Lock Quality?

Alarm Lock Trilogy Networx gateway systems deliver professional-grade network integration with advanced 900 MHz wireless technology and comprehensive software support. The Generation 2 design provides enhanced range capabilities and modern styling with three LED indicators for reliable performance monitoring. Engineered for demanding commercial applications where dependable network connectivity and centralized lock management are essential.
