ALED3T50SFK/D10
ALED3T50SFK/D10 - spec sheet
Features
- 66% energy cost savings vs. HID
- 100,000-hour LED lifespan
- 5-Year, No-Compromise Warranty
ALED3T50SFK/D10 - spec sheet
Manufacturer Resources
Product Specs
- 208v:
- 0.27A
- 277v:
- 0.20A
- Ambient Temperature:
- Suitable For use in 40°C (104°F)
- Bug Rating:
- B1 U0 G2
- Buy American Act Compliance:
- RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
- Color Consistency:
- 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
- Color Stability:
- LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
- Dimming Driver:
- Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims as low as 10%.
- Effective Projected Area:
- EPA = 2.2
- Efficacy:
- 124.3 lm/W
- Equivalency:
- Replaces 200W Metal Halide
- Finish:
- Formulated for high durability and long-lasting color
- Gaskets:
- High-temperature silicone gaskets
- Green Technology:
- Mercury and UV free. RoHS-compliant components.
- Housing:
- Die cast aluminum housing, lens frame and mounting arm
- Iesna Lm 79 Iesna Lm 80 Testing:
- RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
- Input Watts:
- 55.17W
- L70 Lifespan:
- 100,000 hours
- Lifespan:
- 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
- Lumens:
- 6,855
- Patents:
- The ALED™ design is protected by patents pending in the U.S., Canada, China, Taiwan and Mexico.
- Reflector:
- Specular vacuum-metallized polycarbonate
- Thd:
- 6.1% at 120V, 9.4% at 277V
- Ul Listing:
- Suitable for wet locations as a downlight
- Watts:
- 50W
- Weight:
- 32.0 lbs
- Product Group:
- Lighting
- Product Subgroup:
- LED Fixtures
- Department:
- Electrical
