Metallics LCSX5880 Anchors 5/8 x 8 Hx Hd Lg Dia CS St-Gv (Box 10)

Yes. The LCSX5880 is a carbon steel anchor with a galvanized finish, so it holds up better than plain steel in damp interiors, parking structures, and exterior concrete. For continuous saltwater exposure or chemical environments, stainless is the usual move instead of galvanized.

Order it as Metallics LCSX5880. That is both the catalog model and the manufacturer part number, and it covers the 5/8 by 8 inch large diameter hex head anchor in a 10 piece box.

The head is integral. LCSX5880 is a hex head anchor, so you drive it with a socket or impact wrench on the hex and no nut is required to set it. A washer is not supplied in the box of 10, so add one separately if your fixture needs bearing area under the head.

Length is driven by your fixture thickness plus required embedment. An 8 inch anchor like the LCSX5880 is for thick standoffs, heavy base plates, pipe stanchions, or cases where you need to get past a topping slab or non-structural layer into sound concrete. If you are only fastening thin strut or a light bracket directly to the deck, a shorter 5/8 anchor will seat properly without wasting hole depth.

That is exactly the lane for this one. It is catalogued on the electrical side of Metallics line, and a 5/8 by 8 inch galvanized hex head anchor is sized for the heavier end of electrical work: transformer and panel bases, large trapeze and strut runs, and conduit rack stanchions set into concrete.
