Arlington Industries 502L Long Bushed Conduit Nipple, 3/4"

Arlington Industries 502L Long Bushed Conduit Nipple, 3/4"

The Arlington Industries 502L Long Bushed Conduit Nipple is a 3/4" trade size fitting engineered to connect and extend conduit runs between boxes, enclosures, and equipment while safeguarding conductor insulation at the point of connection. Built with a double-chase bushed design, the 502L features factory-installed bushings on both threaded ends, eliminating the need to install separate bushings in the field during rough-in. The extended, or "Long", body length gives installers additional reach compared to a standard short conduit nipple, making it easier to bridge gaps between knockouts, hubs, and couplings in commercial and industrial raceway systems. This bushed nipple design is well suited for panelboards, junction boxes, and other enclosures where a protected, threaded connection point is required.

Key Features

• Trade Size: 3/4" trade size is sized to match standard conduit, box, and enclosure knockouts for a secure, code-compliant fit.
• Bushed (D/C) Design: Double-chase bushed construction places a smooth, factory-installed bushing on each threaded end, shielding conductor and cable insulation from abrasion as wires pass through the fitting.
• Long Length: The 502L's extended length provides greater reach than a standard short nipple, allowing it to span larger gaps between connection points without adding an extra coupling.
• Threaded Connection: Fully threaded ends allow the nipple to be secured directly into couplings, hubs, and box or enclosure knockouts for a solid mechanical and electrical connection.
• Field-Ready Installation: Because the bushings are installed at the factory, electricians can complete the connection without sourcing and fitting separate insulating bushings on the job site.

Technical Specifications

• Refer to manufacturer documentation for complete technical specifications.

Typical Applications

• Conduit-to-Box and Conduit-to-Enclosure Connections
• Extending Conduit Runs in Commercial and Industrial Installations
• Wire and Cable Protection at Threaded Connection Points
• Panelboard and Junction Box Wiring
• New Construction and Retrofit Electrical Projects
• Bridging Conduit Between Knockouts, Hubs, and Couplings

Why Arlington Industries?

Arlington Industries engineers conduit fittings like the 502L bushed nipple to give electricians and contractors a dependable, code-compliant way to join and extend conduit runs. The double-chase bushed construction helps protect conductor insulation at every threaded joint, reducing the risk of damaged wire insulation during and after installation. For commercial and industrial raceway systems that demand reliable, long-lasting connections, the Arlington Industries 502L delivers a straightforward, field-tested solution built for professional electrical work. Whether used to extend a run between two enclosures or to terminate conduit at a panel, the 502L is built to perform as part of a complete Arlington Industries conduit fitting lineup.
