Arlington Industries CPS60 6" Concrete Pipe Sleeve

Arlington Industries CPS60 6" Concrete Pipe Sleeve

(No reviews yet) Write a Review

Model: CPS60

In Stock (leaves warehouse same day if ordered before 3pm ET)

$16.34
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arlington Industries CPS60 6" Concrete Pipe Sleeve

The Arlington Industries CPS60 Concrete Pipe Sleeve is a 6" sleeve designed to create a clean, code-ready opening for pipe or conduit passage through poured concrete floors and walls. Contractors position the sleeve at the planned penetration point during formwork setup, and it remains in place as the concrete cures, defining the finished opening. Because the opening is established before the pour, there is no need to core-drill or break out hardened concrete later to add the pipe passage. This 6" size supports installations where a 6" pipe or conduit run must pass through a poured concrete floor or wall assembly.

Key Features

  • Trade Size: 6" sleeve sized to accommodate 6" pipe or conduit passing through poured concrete.
  • Product Type: Concrete pipe sleeve for creating a defined opening in concrete floors and walls prior to pour.
  • Model CPS60: Part of the Arlington Industries concrete pipe sleeve lineup, identified by the CPS60 designation.
  • Pre-Pour Installation: Positioned in the formwork before concrete is poured, eliminating the need to core-drill or break out cured concrete for the pipe penetration.
  • Construction-Grade Application: Suited for new construction and renovation projects requiring a planned pipe or conduit pass-through in concrete.
  • Available Size: Manufactured in the 6" size to match projects that call out a 6" pipe or conduit sleeve.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • New Construction Concrete Pours
  • Commercial and Industrial Construction
  • Conduit and Pipe Penetrations Through Concrete Floors and Walls
  • Plumbing and Electrical Trade Rough-In Work
  • Renovation Projects Requiring Planned Concrete Penetrations

Why Arlington Industries?

Arlington Industries designs construction and electrical products used by contractors to simplify installation and reduce field labor. The CPS60 concrete pipe sleeve reflects that approach, giving installers a straightforward way to plan and place a 6" pipe penetration before concrete is poured. By engineering the sleeve to be set once and left in place through the pour, Arlington Industries helps installers avoid extra site labor and keep the finished concrete penetration consistent with the plans. Choosing an Arlington Industries product means specifying a component built for the practical demands of the job site.

Manufacturer Resources

Product Specs

list_batch:
ARL-20260918
Product Type:
Pipe Sleeve
Department:
Electrical
Product Group:
Electrical Installation Tools
Product Subgroup:
Installation Aids
Product Size:
5"
Product Width:
6.125 in
Product Color:
Black
Product Height:
8.5 in
Country Of Origin:
United States

Arlington Industries CPS60 – Frequently Asked Questions

1) What does the Arlington CPS60 concrete pipe sleeve actually do on a poured floor?
The CPS60 is a sleeve you set in the formwork before the pour so the concrete cures around it and leaves a finished, defined opening for a pipe or conduit run. Nothing is cut after the fact. It stays in place permanently as the penetration, which is what keeps the opening consistent with what the drawings called out.
2) What size pipe does the Arlington CPS60 sleeve take?
The CPS60 is the 6 inch member of Arlington's concrete pipe sleeve line, sized to accommodate a 6 inch pipe or conduit run passing through the pour. If your drawing calls out a 6 inch sleeve at the penetration, CPS60 is the matching designation.
3) Can I use the CPS60 sleeve on a wall pour, or is it only for floors?
Both. Arlington's CPS60 concrete pipe sleeve is used for pipe and conduit passage through poured concrete floors and walls, so a vertical form works the same way as a deck pour: locate it at the planned penetration point during formwork setup and leave it.
4) Is a pre-set concrete sleeve better than core drilling after the slab is up?
They solve the same problem at different points in the schedule. Setting a CPS60 during formwork means the opening exists the moment the forms strip, with no core drilling and no breaking out cured concrete later. Core drilling is the fallback when the penetration was missed or added after the pour, and it costs you site labor, dust control, and the risk of hitting rebar or post-tension cable. If the pipe run is known at rough-in, the sleeve is the cheaper path.
5) Can the Arlington CPS60 sleeve be used on a renovation, or only new construction?
Both, as long as there is a pour involved. The CPS60 works anywhere concrete is being placed fresh, which on a renovation means new slabs, infill pours, or topping. It will not help you on an existing cured slab, since the sleeve has to be positioned in the formwork ahead of the concrete. For an opening in hardened concrete you are back to coring.
6) How do I specify the right Arlington concrete pipe sleeve for a 6 inch conduit run?
Order by the trade size of the pipe passing through. For a 6 inch pipe or conduit the designation is CPS60, and that is the single size this model covers, so there is no length or finish option to pick alongside it. Larger or smaller penetrations on the same job take a different part number from the Arlington concrete pipe sleeve line.
7) Is the CPS60 an electrical part or a plumbing part? Which trade orders it?
Either. Arlington catalogs the CPS60 with its conduit fittings for electrical rough-in, but the sleeve just forms an opening, so plumbing crews use the same part for pipe pass-throughs. On most jobs whichever trade owns the penetration on the drawing sets the sleeve before the pour.
