Leviton 5ESJK-SC5 Atlas-X1 Cat 5e Shielded QuickPort Jack with Shutters, Crimson

Features

• Available in 13 ANSI/TIA-606-B compatible colors for color coding or organization
• Short connector design supports a wider range of applications (e.g. shallow boxes, enclosures, bend radius, etc.)
• Patented Retention Force Technology (RFT) protects against tine damage from 4- or 6-pin plugs
• Shielding provides EMI/RFI protection, signal isolation, and excellent alien crosstalk (AXT) suppression
• Terminates from 26 to 22-gauge solid or stranded conductors for use on various cable types
• Unique design supports tool-free termination/re-termination and requires no specialized termination tool
• Jack with internal shutter is available to protect against dust and debris
• Robust IDCs can withstand 20 re-termination cycles and connector contacts are tested for 750 plug-mating cycles to ensure system longevity
• Independently tested and guaranteed to exceed all component, permanent link, and channel margins
• Interchangeable icons (voice, data, A/V, and blank, color coded to match the jack face) are available for easy identification and tracking of data, voice, or other functions
