Spec Sheet
Product Specs
- Cam Code:
- Cam 1
- Illumination:
- Illuminated
- Light Unit Type:
- Incandescent, transformer
- Notes:
- Use NEMA 4X 10250T operators where exposed to ultraviolet light
- Number Of Positions:
- Two-position
- Series:
- E34
- Throw Type:
- 60°
- Voltage Rating:
- 24V
- Department:
- Electrical
- Product Type:
- 30.5 mm, Corrosion Resistant
- Product Length:
- 3.4 IN
- Product Details:
- 30.5 mm, Corrosion Resistant
- Performance Rating:
- NEMA 3, 3R, 4, 4X, 12, 13
- Product Height:
- 1.9 IN
- Product Weight:
- .45 LB
- Product Width:
- 2.4 IN
B-LINE E34VFB024 – Frequently Asked Questions
1) What enclosure ratings does the E34VFB024 selector switch carry for washdown or outdoor panels?
It is rated NEMA 3, 3R, 4, 4X, 12 and 13, so it holds up in dust, hose-down washdown and corrosive environments. One limit: for locations exposed to ultraviolet light, use NEMA 4X 10250T operators instead of this corrosion-resistant E34.
2) Is the E34VFB024 an illuminated selector switch, and what voltage does the lamp need?
It is illuminated, using an incandescent lamp with a transformer, and rated 24V. Feed it a 24V control circuit; wiring it to line voltage without the correct supply is the usual mistake on a transformer-type illuminated operator.
3) How many positions does the B-Line E34 selector switch have and how far does the knob rotate?
Two-position, with a 60 degree throw. That makes it a simple on/off or hand/auto style selection, not a three-position center-off. If your control scheme needs a middle position, this is the wrong operator.
4) What cam does the E34VFB024 use, and why does that matter when I add contact blocks?
The operator uses Cam 1. The cam determines which contact blocks make and break at each of the two positions, so when you order contact blocks for a 30.5 mm E34 selector switch, match them to the Cam 1 sequence or the circuit will not switch the way your drawing shows.
5) Can I use the E34VFB024 selector switch in a corrosive or wet plant area like food processing?
Yes, that is what it is built for. It is a corrosion-resistant 30.5 mm operator rated NEMA 4X along with 3, 3R, 4, 12 and 13, which covers washdown and corrosive duty. Keep it out of direct UV exposure and specify NEMA 4X 10250T operators for those spots.
