B4094ZN
Manufacturer Resources
Product Specs
- Certifications:
- Not Applicable
- Product Height:
- 1.37 in
- Product Length Depth:
- 2.87 in
- Product Weight:
- .67 lb
- Product Width:
- 3 in
- Special Features:
- Pre-assembled combination recess hex head machine
- Department:
- Electrical
- Product Group:
- Racks & Frames
- Product Subgroup:
- Racks
- Product Type:
- Porcelain cable rack saddle
- Product Details:
- Porcelain cable rack saddle
- Product Material:
- Porcelain
- Product Length:
- 2.87 in
B-LINE B4094ZN – Frequently Asked Questions
1) What is the B-Line B4094ZN cable rack saddle used for?
The B4094ZN is a porcelain cable rack saddle. It mounts on a cable rack arm in a manhole or vault and cradles the cable, so the cable bears on porcelain rather than on the steel arm itself. Porcelain is the traditional choice for this job because it is non-conductive and stands up to the wet, abrasive conditions underground.
2) What size is the B-Line B4094ZN saddle, and will it clear the cables on my rack arm?
The B4094ZN measures 3 in wide, 2.87 in in length/depth, and 1.37 in high, and it weighs .67 lb. Check that footprint against the spacing between hooks or arms on your rack before ordering, since the 3 in width sets how close together two saddles can sit on the same arm.
3) Does the B4094ZN cable saddle come with mounting hardware, or do I have to order fasteners separately?
Fastening hardware comes with it. The B4094ZN ships with a pre-assembled combination recess hex head machine screw, so the saddle arrives ready to attach without sourcing a separate screw.
4) Is the B-Line B4094ZN made of porcelain or is it a coated metal saddle?
Solid porcelain, not coated steel or plastic. That matters if you are specifying for a utility vault where the saddle has to be non-conductive and resist moisture over a long service life.
5) How many B4094ZN saddles do I need for a run of cable in a manhole?
Order one saddle per support point per cable. Each B4094ZN carries a single cable at one rack arm, so a run supported at four arms needs four saddles for each cable, and a vault with three cables on those same arms needs twelve. At .67 lb each, count the total before you order so you are not short a support mid-install.
