B-Line Eaton series all threaded rod and drop wire supports, 160 lb load capacity, Steel, 9/16" to 3/4" flange thickness, 3/8" rod, Rod to beam hanger

The BH2-E-9-12 rod-to-beam hanger is sized for flanges 9/16 inch through 3/4 inch thick. Thinner flanges need a different size in the BH2 range, so measure the flange edge on the bar joist or beam before ordering. Outside that 9/16 to 3/4 inch window the clip will either not seat or will not grip.

It is cULus Listed, which is what an inspector on a commercial or institutional job normally wants to see on a support used to hang conduit, raceway, or lighting from structural steel. That listing applies to the clip itself.

That is the point of it. The BH2-E series clip slides onto the beam or joist flange and gives you a threaded rod attachment point with no drilling, welding, or hot work permit. For electrical contractors running conduit or fixture drops overhead in existing steel, it is the fast route; where there is no exposed flange to grab (concrete deck, wood framing) you need a different family of anchor entirely.

No. The BH2-E-9-12 is the beam attachment clip only. The threaded rod, nuts, and whatever hangs off the bottom (conduit strap, trapeze channel, fixture hanger) are ordered separately.

Compact steel stamping: 2.75 in height, 1 in length/depth, .56 in width, and .065 lb each. Low enough profile that it clears tight plenum space above ceiling grid, and light enough that a box of them adds nothing meaningful to a material handling count.
