B-Line Eaton Series C electron...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$41,256.49
B-Line Eaton Series C electronic , L-, LDC, Complete , OPTIM 550, Electronic LSIG trip, Three-pole, 400A, 600 Vac, 250 Vdc, Without terminals, 50/60

B-Line Eaton Series C electronic , L-, LDC, Complete , OPTIM 550, Electronic LSIG trip, Three-pole, 400A, 600 Vac, 250 Vdc, Without terminals, 50/60

(No reviews yet) Write a Review

Model: LDC3400T56W
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$41,256.49
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton Series C electronic molded case circuit breaker, L-frame, LDC, Complete breaker, OPTIM 550, Electronic LSIG trip, Three-pole, 400A, 600 Vac, 250 Vdc, Without terminals, 50/60 Hz

LDC3400T56W - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Amperage Rating:
400A
Catalog Notes:
Long delay I4t response seletion limits short delay time to flat response. One Form C auxiliary switch and one Form C bell alarm switch supplied with breaker as standard. Factory sealed.
Certifications:
UL Listed
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
LDC
Frame:
L-frame
Frequency Rating:
50-60 Hz
Interrupt Rating:
200 kAIC at 240 Vac, 100 kAIC at 480 Vac
Number Of Poles:
Three-pole
Product Height:
8.25 IN
Product Length Depth:
13 IN
Product Weight:
13 LB
Product Width:
8.25 IN
Series:
Series C
Terminals:
Without terminals
Trip Type:
Electronic LSIG
Voltage Rating:
600 Vac, 250 Vdc
Department:
Electrical
Product Length:
13 in

B-LINE LDC3400T56W – Frequently Asked Questions

1) Does the Eaton LDC3400T56W breaker come with lugs or terminals?
No. The LDC3400T56W is supplied without terminals, so you have to order the line and load lug or terminal kit separately for the L-frame LDC breaker. Budget for that before the install date, because the breaker cannot be landed on cable as shipped.
2) What interrupting rating does the 400A Eaton LDC L-frame breaker have at 480V?
100 kAIC at 480 Vac, and 200 kAIC at 240 Vac. That is the number your short circuit study has to be checked against; if the available fault current at the panel exceeds it at your system voltage, this breaker is not the right selection.
3) What does the OPTIM 550 LSIG trip unit give me over a thermal-magnetic breaker?
LSIG means four adjustable functions: long delay, short delay, instantaneous, and ground fault. A thermal-magnetic breaker only gives you the long-time and instantaneous behavior fixed by its thermal element. With LSIG you can coordinate selectively with upstream and downstream devices and get integral ground fault protection without a separate relay and CT set. Note the trip unit is factory sealed, and selecting the long delay I4t response limits the short delay time to a flat response.
4) Do I need to buy an auxiliary switch and bell alarm separately for this Eaton LDC breaker?
No, both are already in the box. One Form C auxiliary switch and one Form C bell alarm switch ship with the breaker as standard, so you can wire breaker status and trip indication back to your BMS or annunciator panel without a field-installed accessory.
5) Is the LDC3400T56W a complete breaker or just a trip unit replacement?
Complete breaker. The LDC3400T56W ships as a whole Series C L-frame unit with the OPTIM 550 electronic trip already fitted, not as a bare trip unit or a replacement interior. It is also UL Listed.
6) How much space and weight do I need to allow for a 400A Eaton L-frame breaker?
The unit measures 8.25 inches high, 8.25 inches wide, and 13 inches deep, and weighs 13 pounds. Allow for the terminal kit beyond that depth since the breaker ships without terminals, and plan on two hands or a lift for panel mounting at that weight.
7) Can the trip settings on the LDC3400T56W be field adjusted after installation?
The breaker is factory sealed, so treat the unit as a sealed assembly rather than something to open up in the field. Order the 400A frame rating you need up front; the amperage rating on this one is 400A on the L-frame.
