Eaton B-Line series datacomm and low voltage support fasteners, 1/8" to 1/4" flang thickness, 3/4" hook size, Pre-galvanized, 30 lb load capacity, Steel, Cable to beam fastener
Manufacturer Resources
Product Specs
- Certifications:
- UL/CUL listed
- Hook Size:
- .75 in
- Load Capacity:
- 30 lb
- Product Height:
- 6.465 in
- Product Length Depth:
- 4.962 in
- Product Weight:
- .561 lb
- Product Width:
- 2 in
- Special Features:
- 1/8" to 1/4" flang thickness
- Department:
- Electrical
- Product Group:
- Fasteners
- Product Subgroup:
- Other Fasteners
- Product Type:
- Cable to beam fastener
- Product Finish:
- Pre-galvanized
- Product Details:
- Cable to beam fastener
- Product Material:
- Steel
- Product Length:
- 4.962 in
B-LINE BCH64-E24 – Frequently Asked Questions
1) Will the B-Line BCH64-E24 beam clamp fit the flange on my bar joist or I-beam?
The BCH64-E24 is built for beam flanges from 1/8 inch up to 1/4 inch thick. That covers typical light structural steel and bar joist angle in commercial ceilings. If your flange is thicker than 1/4 inch, this clamp will not seat on it and you need a heavier flange-range clamp instead.
2) Is this B-Line fastener UL listed for low voltage cable support?
Yes. The BCH64-E24 datacomm and low voltage support fastener is UL/CUL listed, which is what most inspectors and institutional specs want to see on cable support hardware above a ceiling.
3) Do I need any tools or extra hardware to install this cable to beam fastener?
No drilling, no anchors, no welding. The BCH64-E24 is a clamp-on cable-to-beam fastener, so the hook and the beam attachment come as one piece and it snaps onto the beam flange within its 1/8 to 1/4 inch range. That is the point of the part, it saves the extra clamp and threaded rod an independent J-hook would need.
4) Can I use the pre-galvanized B-Line cable hook in a damp or unheated space?
The body is steel with a pre-galvanized finish, which handles indoor and normally dry-to-damp environments such as plenums, parking structures and unheated mechanical rooms. For continuously wet, corrosive or exterior exposure, specify a stainless or hot-dip galvanized cable support instead.
5) How much clearance do I need above the ceiling for the B-Line BCH64-E24?
Plan for the assembly's stated size of 6.465 x 4.962 x 2 inches. In a tight plenum, check the vertical drop between the beam flange and the ceiling grid before you commit to a whole floor's worth. Each piece weighs .561 lb, which is useful when you are figuring how many to carry up per box.
6) Is the B-Line BCH64-E24 rated for electrical power wiring or just data cable?
It is a datacomm and low voltage support fastener. Use it for structured cabling, coax, fiber and similar low voltage runs. Branch circuit power wiring is supported under different rules and typically needs a straps-and-clamp method suited to that wiring method, so do not substitute this hook for it.
