Eaton B-Line series Flextray wire basket tray, 32" width, Steel
Manufacturer Resources
Product Specs
- Certifications:
- UL Classified
- Compliances:
- CSA
- Product Height:
- 6.44 in
- Product Length Depth:
- 33 in
- Product Weight:
- 1.7 lb
- Product Width:
- 32 in
- Department:
- Electrical
- Product Material:
- Steel
- Product Length:
- 33 in
B-LINE FTB32T – Frequently Asked Questions
1) What size cable basket tray is the B-Line FTB32T, and how much cable space does it give me?
The FTB32T is a 32 inch wide Flextray wire basket tray with a 6.44 inch overall height, so it carries a wide bundle of communications or power cable in a single run. Overall length/depth is listed at 33 inches. It's a steel tray, part number FTB32T from Eaton's B-Line series.
2) Is the B-Line Flextray FTB32T basket tray UL Classified and acceptable in Canada?
Yes on both counts. The Flextray FTB32T carries a UL Classified marking and is listed as CSA compliant, which is what a facility or institutional spec usually asks for on a cable management run.
3) Does the FTB32T Flextray come with hangers, splices or mounting hardware?
No. The FTB32T is the tray section itself, 32 inches wide in steel. Splice connectors, hold-down clamps, trapeze or wall brackets, threaded rod and drop-in anchors are all separate line items on a Flextray order, so build them into your takeoff before you order the straight sections.
4) Will a 32 inch wide basket tray fit above my ceiling grid?
Plan on more than 32 inches of clear corridor: the tray is 32 inches wide with a 6.44 inch height, and you still need room above it for threaded rod, the hanger bracket, and hand access to drop cable in from the top. In tight plenums a 32 inch tray often has to sit below the structure on a trapeze rather than tuck between joists, so check your clear dimension before committing to this width.
5) Is a 32 inch wire basket tray light enough for a single installer to hang overhead?
The FTB32T section weighs 1.7 lb, so the tray itself is a one-person lift even at 32 inches wide. What drives your support design is the cable fill, not the tray. Space your hangers and trapeze supports for the loaded weight of the bundle you're running.
6) Should I use a wire basket tray like the Flextray or solid/ladder cable tray?
Wire basket like the Flextray FTB32T is the usual choice for low-voltage and data cabling: the open mesh sheds dust, lets you drop cable in anywhere along the run instead of pulling it end to end, and it can be field-cut and bent to form offsets and turns without ordering fittings. Solid-bottom or ladder tray is the better call where you need cable shielding, a defined bottom for heavy power feeders, or where the spec calls out a specific tray class. The Flextray is steel and 6.44 inches deep in this size.
7) I'm standardizing tray across a building. Is FTB32T the same Flextray family as the narrower widths?
Yes. FTB32T is the 32 inch width in Eaton's B-Line Flextray wire basket line, so it splices and mates with the other widths in the same series using the same connector hardware. Use the wide 32 inch sections on your main risers and backbone runs, and step down to narrower widths on branch runs off the main.
