Eaton B-Line series Flextray wire basket tray, Used with (SB301-1/2 X 8) threaded rod protector, Pregalvanized zinc, Steel, 18" center trapeze hanger
Manufacturer Resources
Product Specs
- Application:
- (SB301-1/2 x 8) threaded rod protector
- Certifications:
- cULus Listed
- Product Height:
- 1.77 in
- Product Length Depth:
- 21.59 in
- Product Weight:
- 1.77 lb
- Product Width:
- .78 in
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Center trapeze hanger
- Product Finish:
- Pre-galvanized
- Product Details:
- Center trapeze hanger
- Product Material:
- Steel
B-LINE FTB18CT – Frequently Asked Questions
1) Do I need anything else to hang Flextray with the FTB18CT trapeze hanger?
Yes, the hanger is the cross member only. It is used with the SB301-1/2 x 8 threaded rod protector, and you supply the threaded rod, nuts and washers, and whatever anchors suit your deck or structure. Order the rod protectors and rod alongside the hangers so the run is complete on the first trip.
2) Is the B-Line FTB18CT trapeze hanger listed for electrical cable tray support?
It is cULus Listed, which covers it for both US and Canadian installations. That matters on institutional and commercial jobs where the inspector wants the support hardware listed, not just the tray.
3) Can the FTB18CT hanger be used in a damp area like a parking garage or warehouse?
The hanger is steel with a pre-galvanized zinc finish, which suits dry and normally dry indoor runs and typical unconditioned interior space. Pre-galvanized is a mill coating, so cut ends and exposed edges are the weak point. For wash-down areas, corrosive process environments, or full outdoor exposure, specify a hot-dip galvanized or stainless support instead.
4) What does a center trapeze hanger do that a standard trapeze does not?
A center trapeze hanger picks the Flextray basket up from a single rod pair at the middle of the run rather than bracketing the tray with side rails. It keeps the sides of the basket clear so you can drop cable in from either side and add or remove conductors later without unbolting the support. If you need the tray fully cradled or you are stacking multiple trays on one rod set, a conventional trapeze assembly is the better call.
5) Will this hanger work with another manufacturer's wire basket tray?
The FTB18CT is built as part of the Eaton B-Line Flextray system and is specified for 18 inch Flextray basket. Wire sizes, mesh spacing and side rail height vary between manufacturers, so if you are supporting a different brand of basket, match the support to that system rather than mixing it with Flextray hardware.
