Eaton B-Line series hanging system, KwikWire accessories, Loop termination, 1/16" wire max, 240" wire length
Manufacturer Resources
Product Specs
- Certifications:
- cULus Listed
- Product Diameter:
- .0625 in
- Product Height:
- 240 in
- Product Weight:
- 2.49 lb
- Wire Diameter Max:
- .062 in
- Wire Length:
- 240 in
- Department:
- Electrical
- Product Type:
- Loop termination
- Product Model:
- KwikWire accessories
- Product Details:
- Loop termination
B-LINE BKL-063-240K – Frequently Asked Questions
1) Is the B-Line KwikWire hanging system listed for electrical work?
It is cULus Listed, so it is recognized for both US and Canadian installations. That matters for inspectors on commercial lighting, cable tray, and suspended equipment jobs where every component in the support path has to be a listed item.
2) What does the loop end on a KwikWire hanger do, and what do I attach it to?
Loop termination means the far end of the wire is formed into a closed loop rather than a threaded stud or hook. You pass a bolt, eye bolt, beam clamp hook, or threaded rod fitting through the loop to anchor it to the structure, then the KwikWire gripper on the other end takes the load and lets you adjust height by squeezing the release. It is the end type to order when your anchor point already gives you something to pass through; pick a threaded or toggle end instead if you need the hanger itself to fasten into the deck.
3) Do I get one hanger per order of BKL-063-240K, and what does it weigh?
BKL-063-240K is a single kit, the only model on the line, and it weighs 2.49 lb. On a job needing four-point suspension per fixture, count four kits per fixture when you build the order.
