B-Line Eaton series open rack...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$256.54
B-Line Eaton series open racks, 2.4" height, 5.5" length, 19" width, Steel, RCM rack mounted single sided horizontal cable manager, Plastic finger, S

B-Line Eaton series open racks, 2.4" height, 5.5" length, 19" width, Steel, RCM rack mounted single sided horizontal cable manager, Plastic finger, S

(No reviews yet) Write a Review

Model: SB87019S2SL
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$256.54
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series open frame racks, 2.4" height, 5.5" length, 19" width, Steel, RCM rack mounted single sided horizontal cable manager, Plastic finger, Silver powder coat

Manufacturer Resources

Product Specs

Application:
Provide horizontal pathway for cabling on one side
Certifications:
UL
Material Details:
Silver powder coat, black plastic components
Material Thickness:
14 gauge
Product Height:
2.4 in
Product Length Depth:
5.5 in
Product Weight:
2.5 lb
Product Width:
19 in
Special Features:
Fully compatible with RCM vertical cable manager
Department:
Electrical
Product Model:
RCM rack mounted single sided horizontal cable manager
Product Color:
Silver
Product Style:
Plastic finger
Product Material:
Steel
Product Length:
5.5 in

B-LINE SB87019S2SL – Frequently Asked Questions

1) Will the Eaton B-Line SB87019S2SL cable manager mount in a standard 19 inch rack?
Yes. The SB87019S2SL is a 19 inch wide rack mounted horizontal cable manager, so it bolts into standard 19 inch EIA rack rails on an open frame rack or cabinet. It stands 2.4 inches high, which is a nominal 1U-plus panel space, and projects 5.5 inches in depth off the rails.
2) Does this B-Line RCM manager route cable on both sides of the rack or only one?
One side only. The RCM single sided horizontal manager gives a horizontal pathway for cabling on one side of the rack. If you need patch cords dressed front and rear, you need two units or a double sided manager.
3) Can I use this horizontal manager together with B-Line RCM vertical cable managers?
Yes, it is fully compatible with the RCM vertical cable manager, so horizontal runs at the patch panels hand off into the vertical channels on the rack uprights without adapters.
4) Is the SB87019S2SL steel or plastic, and how heavy is it?
The body is 14 gauge steel with a silver powder coat, and the cable fingers are black plastic. The whole unit weighs 2.5 lb, so it adds almost nothing to rack load and one person can hold it while starting the mounting screws.
5) Will a silver cable manager match my existing black rack?
No. This one is finished in silver powder coat with black plastic fingers. If your racks and panels are black, the silver face will read as a mismatch across the front of the rack, and you would want a black finish version instead.
6) Is this cable manager UL listed for a data room installation?
The SB87019S2SL carries a UL certification, which is typically what a facility or institutional spec calls out for rack accessories in a telecom or data room.
7) Finger style versus a solid duct horizontal manager, which should I use at the patch panel?
This is a plastic finger style manager. Open fingers let you drop or pull individual patch cords in and out from the front without threading the whole bundle through a closed duct, which is what you want directly above and below patch panels where moves and changes happen. A solid duct or D-ring panel makes more sense for permanent trunk cable you do not expect to touch.
8) What part number do I order for the B-Line single sided silver horizontal manager?
Order Eaton B-Line MPN SB87019S2SL. That is the 19 inch, single sided, plastic finger horizontal cable manager in silver powder coat.
