B-Line Eaton series other encl...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$244.87
$230.69
B-Line Eaton series other enclosure accessories, ANSI 61 gray polyester powder coated, 2 inch, Protects openings, pushbuttons and conduit openings, St

B-Line Eaton series other enclosure accessories, ANSI 61 gray polyester powder coated, 2 inch, Protects openings, pushbuttons and conduit openings, St

(No reviews yet) Write a Review

Model: S200SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$244.87
$230.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series other enclosure accessories, ANSI 61 gray polyester powder coated, 2 inch, Protects openings, pushbuttons and conduit openings, Stainless steel, Oil-tight Hole seals, Hole seals

Manufacturer Resources

Product Specs

Application:
Protects openings, pushbuttons and conduit openings
Certifications:
UL Listed
Finish Color:
ANSI 61 gray painted
Product Category:
Hole seals
Product Diameter:
3 in
Product Height:
4.375 in
Product Weight:
.38 lb
Department:
Electrical
Product Type:
Oil-tight Hole seals
Product Details:
Oil-tight Hole seals
Product Material:
Stainless steel

B-LINE S200SS – Frequently Asked Questions

1) What size opening does the B-Line S200SS hole seal cover?
The S200SS is the 2 inch hole seal in the Eaton B-Line oil-tight line, meaning it plugs a 2 inch knockout or punched opening. The seal body itself measures 3 inches in diameter, so allow room on the panel face around the hole for the flange to seat flat.
2) Is this hole seal rated oil-tight for a washdown or machine-shop enclosure?
Yes. It is an oil-tight hole seal and it is UL Listed, so it is intended for sealing unused openings in enclosures where oil and coolant spray are present, such as machine tool panels. It seals the hole; it does not raise the rating of an enclosure that was never built to it.
3) Can I use the S200SS to close off an abandoned pushbutton or conduit hole in a control panel?
That is exactly the application. Eaton B-Line lists it for protecting openings, pushbuttons and conduit openings, so it works for a removed 2 inch pilot device hole or a conduit entry you no longer need to feed.
4) What is the S200SS hole seal made of, and will it hold up outdoors?
The body is stainless steel with an ANSI 61 gray polyester powder coat, so you get corrosion resistance from the base metal plus a painted finish. The gray also matches the standard ANSI 61 gray on most industrial enclosures, so it blends into the panel rather than standing out.
5) How much clearance do I need behind the panel to install this 2 inch hole seal?
Allow about 4-3/8 inches on the height dimension, since that is the overall height Eaton publishes for the S200SS. On a shallow enclosure or a door with devices mounted close behind it, check that dimension against your available depth before you commit.
