Product Specs
- Full Load Current Range:
- 0.384A 0.464A 0.543A 0.623A Dial positions A B C D respectively
- Notes:
- Heater packs are shipped 3 to a carton. Catalog Numbers and prices are for 3 heater packs.
- Overload Relay:
- 32 or 75A
- Trip Type:
- Fast Trip, Class 10
- Used With:
- Used with starter sizes 00-0 (Series C), Sizes 1-2 (Series B), IEC Sizes A-F (Series C), IEC Sizes G-K (Series B)
- Department:
- Electrical
- Product Design:
- NEMA, IEC
B-LINE H2102B-3 – Frequently Asked Questions
1) How many heater packs come with B-Line H2102B-3, or is that a single pack?
H2102B-3 heater packs ship three to a carton, and the catalog number covers all three. So one order gets you a set of three, which is what a three-phase starter needs, one per pole.
2) What motor current range does the H2102B-3 heater pack cover?
It covers 0.384A, 0.464A, 0.543A and 0.623A at dial positions A, B, C and D respectively. Pick the dial setting that matches your motor's full load amps, which is why this pack only suits very small motors or control circuits in that fractional-amp band.
3) Which starter sizes does the B-Line H2102B-3 heater pack fit?
NEMA starter sizes 00 through 0 in Series C, NEMA sizes 1 and 2 in Series B, IEC sizes A through F in Series C, and IEC sizes G through K in Series B. If your starter falls outside those size and series combinations, this is the wrong heater pack.
4) Will these heater packs work in both NEMA and IEC overload relays?
Yes. The heater pack is built for both NEMA and IEC designs, and it goes into 32A or 75A overload relays. That matters on mixed panels where some starters are NEMA Freedom and others are IEC.
5) Is the H2102B-3 a fast trip or standard trip heater pack?
Fast Trip, Class 10. Class 10 trips within 10 seconds at locked rotor current, so use it where the motor or load needs quick protection, such as submersible pumps and hermetic loads. If your motor has a long acceleration time, a Class 10 fast trip element can nuisance trip.
6) Where do I find the dial setting chart for the B-Line H2102B-3 heater pack?
The manufacturer spec sheet for H2102B-3 is linked from the product information and carries the full selection data. On the part itself, dial positions A through D correspond to 0.384A, 0.464A, 0.543A and 0.623A full load current.
