BALDWIN ESTATE 5066 OVAL KNOB ONLY OVERVIEW
KEY FEATURES
- Exquisite lines complement the round design of this smooth and stylish knob.
- Sold as a pair or an individual, knobs and levers can be used to create your own unique look.
- Pair mix and match knobs and levers with roses for interior sets like passage and privacy, or customize mortise lock sets utilizing handle set trim or a wide variety of escutcheon plates.
- This style is featured in Quick Ship as part of a complete Passage, Privacy, Full Dummy or Half Dummy set.
- Familiar and comforting, this item in its traditional style is timeless and classic.
RESOURCES & DOWNLOADS
Manufacturer Resources
Product Specs
- Product Group:
- Door Trim and Accessories
- Product Type:
- Knob Handle
- Subcategory:
- Parts and Accessories
- Product Subgroup:
- Knob Handle
- Commercial/Residential:
- Residential
- Collection:
- Estate Series
- Knob Diameter:
- 2.2"
- Maximum Door Thickness:
- 1.75"
- Minimum Door Thickness:
- 1.375"
- Product Model:
- 5066
- Product Projection:
- 2.7"
- Product Category:
- Door Trim and Accessories
- Department:
- Door Hardware
Baldwin 5066033MR – Frequently Asked Questions
1) Does the Baldwin Estate 5066 knob come with a rose or rosette, or is it knob only?
The Estate 5066 is the knob itself, no rose and no latch. Baldwin sells the knobs separately so you can pair them with roses for interior passage and privacy sets, or with handle set trim or escutcheon plates on a mortise lock. Plan on ordering the rose or escutcheon and the lock or latch mechanism alongside it.
2) Should I order the 5066 as a half pair or a pair?
Three choices: Half Pair, Pair, and Pair (PINNED). A half pair is one knob, which is what you want for a half dummy or to replace a single damaged knob. A pair covers both faces of the door for passage, privacy, or full dummy. Pair (PINNED) is the pinned version where the knob is pinned to the spindle rather than left loose.
3) Will the Baldwin 5066 knob work on a 1-3/8 inch door?
Yes. The 5066 is rated for doors from 1-3/8 inch up to 1-3/4 inch thick, so it covers both the common older interior thickness and standard 1-3/4 inch doors.
4) How far does the 5066 knob stick out from the door face?
Projection is 2.7 inches off the door, with a knob diameter of 2.2 inches. That matters where a door swings back against a wall, a tight closet return, or beside trim or a cabinet where knuckle clearance is short. Check the swing path before committing on a narrow hallway or a door that opens against casing.
5) Is the Baldwin Estate 5066 knob suitable for a commercial building or office corridor?
It's a residential product. Baldwin classes the Estate 5066 as residential door hardware, so for a commercial corridor or a high-traffic institutional opening you want a graded commercial lockset instead. It suits homes, condo interiors, and high-end multi-family unit interiors.
6) Can I mix the 5066 oval knob with Baldwin levers on other doors in the same house?
Yes. Baldwin sells Estate knobs and levers individually or in pairs specifically so they can be mixed and matched with roses to build your own look, so you can run levers on the doors that need them and the 5066 oval knob elsewhere, keeping the same finish across the openings.
7) What finishes does the Baldwin 5066 knob come in if I need to match existing Baldwin hardware?
Fourteen finishes: 003 Polished Brass, 031 Non-Lacquered Brass, 033 Vintage Brass, 044 Satin Brass PVD, 050 Satin Brass Black, 055 Polished Nickel PVD, 056 Lifetime PVD Satin Nickel, 060 Satin Brass Brown, 076 Lifetime PVD Graphite Nickel, 102 Oil Rubbed Bronze, 112 Venetian Bronze, 190 Satin Black, 260 Polished Chrome, and 402 Distressed Oil Rubbed Bronze. Match by the Baldwin number stamped or listed on your existing trim rather than by the finish name, since brass and bronze tones vary.
8) Can I use the 5066 knob to replace a knob on an existing Baldwin mortise lock?
That is one of its intended uses. The Estate 5066 knob is meant to be combined with handle set trim or escutcheon plates to make up a mortise lock set, so it works as trim over a mortise lock rather than as a complete lock in itself. You supply the escutcheon or rose and the mortise body.
9) Is there a drilling template for installing the 5066 knob and rosette?
Baldwin publishes a 5066 Knob With Rosette template, linked in the product resources, which gives the hole locations for the rose. Use it against your existing bore before you drill, especially on a retrofit where the old rose covered a larger hole.
