Baldwin Reserve Kodiak Full Dummy Entry Handleset with Interior Egress Options

No. The Kodiak full dummy set has no latch and no locking mechanism, so the door it goes on has to be held shut some other way, usually by the active leaf of a pair or by a flush bolt. It is a pull on both faces, nothing more. If you need the door to latch, order the keyed or passage version of the handleset instead.

It is a full dummy set, meaning both halves are in the box: the exterior handleset and the matching interior trim. You pick the inside trim as part of the order, either the RUS rustic knob, the ARC arch lever, or the TAP taper lever.

Handing matters on the lever trims only. Both the ARC arch lever and the TAP taper lever are ordered as left handed or right handed, so you need to know which way the door swings and which face the lever sits on. The RUS rustic knob is symmetrical and has no handing to call out.

Put the Kodiak full dummy on the inactive leaf and a passage or keyed handleset of the same style on the active leaf. That gives you a matched pair where one door actually latches and locks and the other is just a pull.

The Kodiak is a full dummy handleset, meaning no latch and no locking mechanism, with both interior and exterior trim supplied. Direct dummy-function alternatives include the Weslock 2815 Hillcrest Dummy Handleset with New Heaven Lever and the Weslock 6695 Belmont Dummy Handleset with Impresa Knob, both of which list a 1-3/8 to 2 inch door thickness range. On the Emtek side, the 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan are all brass mortise entrance handlesets in dummy function. Choose on trim style and finish, since the function is the same inactive-leaf pull in each case.

The Kodiak dummy starts at 1-3/4 inch as its standard door thickness, so a 1-3/8 inch door calls for a different unit. The Pamex FS7P31 Lexington single cylinder handleset in satin nickel lists 1-3/8 to 1-3/4 inch in entry function. Weslock's 2810 Hillcrest single cylinder with Hudson knob and the 2815 Hillcrest dummy with New Heaven lever both cover 1-3/8 to 2 inch, giving you a latching and a dummy option on the same thinner door.

The interior egress rose is the escutcheon the inside knob or lever mounts to. Two shapes are offered: RAE, a rustic arched interior egress that follows the arched exterior plate, and SBE, a square bevel interior egress for a squarer look. Both shapes pair with any of the three inside trims.

Two finishes: 481 Dark Bronze and 492 White Bronze. Interior trim ships in the same finish as the exterior by default. If you want a split finish, there is an optional field on the order where you state the two finishes you want.

Edge bore is 1 inch. Since it is a dummy with no latch, there is no latch to install in that edge bore, but the prep dimension is what Baldwin publishes for the set. Plan the door prep to the Reserve full dummy installation guide that ships with it.

It is catalogued as a residential product and Baldwin states it is tested to exceed ANSI/BHMA Grade 2 security. For light commercial entries that is often acceptable, but a Grade 1 specification on a drawing will not be met by this set.

No. It is non-keyed with no cylinder and no keying option, so there is nothing to key or rekey. If the opening needs a key, you need a keyed handleset such as the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever, or a Sure-Loc Madison keyed entry handleset.

No. The Kwikset 687AMD is an entrance-function single cylinder keyed handleset, Grade 3, supplied exterior only for 1-3/4 inch doors, whether ordered as the SmartKey 687AMD SMT or the SC1 keyway 687AMD SMC version. The Kodiak is a non-keyed dummy set that ships with both interior and exterior trim and has no latch at all. They look similar on the door face but serve opposite purposes, and the Kwikset exterior-only packaging means no inside trim comes with it.

The Kodiak carries a rustic design with a 1 inch edge bore and interior egress rose choices of rustic arched or square bevel, but it is a dummy with no latch, so backset is not a factor. If your opening needs a latching handleset with backset flexibility, the Sure-Loc handlesets list an adjustable backset: the Aspen AN507 and Madison MA507 in keyed entry, the Alta AT507 as a tubular handleset, and the Coral CR507. Those are latching handlesets rather than dummy sets, so plan the prep accordingly.

The Kodiak dummy handles the inactive leaf with no latch or lock. For the active leaf with electronic control, the Kwikset 815SCEHFL-CP913CNT San Clemente handleset pairs a Halifax lever interior trim with a contemporary SmartCode keypad electronic deadbolt for 1-3/4 inch doors. Yale Real Living offers the BYRD226CBARX Assure Lock with Wi-Fi and Bluetooth touchscreen deadbolt and Ridgefield handleset and the BYRD226NRRX standalone touchscreen version, both listed at 1-3/4 to 2-1/4 inch. Styling will differ from the Kodiak's rustic design, so confirm the aesthetic match before committing.

The Baldwin Reserve Kodiak is a residential product tested to exceed ANSI/BHMA Grade 2 security. If a peer with a published Grade 2 rating is required on the submittal, the Schlage Residential F60 Addison keyed entry handleset and the JE285 Barcelona non-keyed handleset both list Grade 2 for 1-3/8 to 1-3/4 inch doors, as does the Schlage JI18/19 interconnected passage lock with keyed deadbolt and Torino lever. The Master Lock HDLBA0615/4D single cylinder deadbolt handleset in the HDLB Series is also Grade 2 in entrance function.

No. The Deltana 803871B Hanover, 815871 St. Ann, and 825871 Kingston are all solid brass handlesets in entry function, so each includes a latching mechanism the Kodiak does not have. The Kodiak is a non-keyed dummy with no latch and no lock, used as a pull. The Deltana 810871 Montego handleset lists a 1-3/8 to 2 inch door thickness range. Use the Deltana units where the leaf must latch and the Kodiak where it stays fixed.

Yes, it is part of Baldwin's Reserve Series with a rustic design, so it keys visually to other Reserve trim in the same 481 Dark Bronze or 492 White Bronze finish. Ordering the same interior rose and lever or knob style across openings is what keeps the fleet consistent.

The Kodiak is a dummy only, with no latch, so a lock always has to come from a second unit. If consolidating into one key-free assembly suits the opening better, the Yale Real Living BYRD256 CBARX Assure key free touchscreen deadbolt with Ridgefield passage handleset and trim connected by August lists Wi-Fi function for 1-3/4 to 2-1/4 inch doors, and the BYRD410BLERX Assure Lock 2 key-free touchscreen deadbolt with Wi-Fi and Ridgefield handleset covers 1-3/8 to 2-1/4 inch. Those are single-leaf solutions and will not serve an inactive leaf the way the Kodiak does.

The Kodiak offers a rustic knob for the inside trim alongside left and right handed arch and taper levers, in dark bronze or white bronze, with rustic arched or square bevel interior egress roses. For a knob interior on a dummy handleset from another maker, the Weslock 6695 Belmont Dummy Handleset with Impresa Knob is a dummy function unit for 1-3/8 to 2 inch doors. In a latching version, the Weslock 2810 Hillcrest single cylinder handleset uses a Hudson knob and the Weslock 1411 Traditionale Colonial uses an Eleganti knob.
