BEST BP80 HD8000 Top Jamb Backplate

BEST BP80 HD8000 Top Jamb Backplate for Door Closer Installation

(No reviews yet) Write a Review

Model: BP80 689
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$102.00
$69.75
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST BP80 HD8000 Top Jamb Backplate for Door Closer Installation

Professional Door Closer Mounting Solution

The BEST BP80 HD8000 Top Jamb Backplate provides a specialized mounting solution for door closer installations where frame face dimensions are less than 2-7/8" (73 mm). This professional-grade backplate features dual mounting hole configurations to accommodate either 1-3/4" (44 mm) or 3-1/4" (83 mm) minimum ceiling clearance requirements. Engineered specifically for the HD8000 series, this backplate enables both top jamb drop applications and regular mount configurations to clear various stop and holder installations.

Professional Features & Benefits

  • Frame Compatibility: Designed for mounting when frame face is less than 2-7/8" (73 mm) for versatile installation options.
  • Dual Clearance Options: Two sets of mounting holes accommodate 1-3/4" (44 mm) or 3-1/4" (83 mm) minimum ceiling clearance requirements.
  • Top Jamb Drop Application: Top set of holes create specialized drop application to clear surface applied stop/holder configurations.
  • Regular Mount Capability: Can be used for standard mounting to clear mortised overhead stop/holder installations.
  • HD8000 Series Compatibility: Specifically engineered for use with BEST HD8000 series door closers for optimal performance.
  • Professional Construction: Heavy-duty backplate design ensures secure mounting and long-term reliability in commercial applications.

Technical Specifications

  • Department: Door Hardware
  • Product Attribute: Parts and Accessories
  • Product Category: Door Controls
  • Product Group: Parts and Accessories
  • Product Model: BP80
  • Product Subgroup: Parts and Accessories
  • Product Type: Door Closer Parts and Accessories
  • Series: HD8000
  • Subcategory: Parts and Accessories

Installation & Operation

This mounting backplate is designed for use with compatible BEST HD8000 series door closers. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose BEST Quality?

BEST door closer accessories deliver professional-grade reliability with heavy-duty construction designed for demanding commercial applications. The BP80 backplate provides the specialized mounting solution needed for challenging frame configurations while maintaining the performance standards expected from BEST hardware. Engineered for demanding commercial applications where dependable door closer operation is essential.

Manufacturer Resources

BEST Product Overview

Product Specs

Subcategory:
Parts and Accessories
Series:
HD8000
Product Group:
Parts and Accessories
Product Type:
Door Closer Parts and Accessories
Product Attribute:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Model:
BP80
Product Category:
Door Controls
Department:
Door Hardware

BEST BP80 689 – Frequently Asked Questions

1) What is the BEST BP80 backplate used for on a door closer installation?
The BP80 is a top jamb backplate for BEST HD8000 series door closers. It goes between the closer body and the frame head when the frame face measures less than 2-7/8 inches (73 mm), which is too narrow to take the closer's mounting pattern directly. It is a mounting plate, not a closer and not an arm, so you still order the HD8000 closer itself.
2) My door frame head is narrower than 2-7/8 inches. Can I still top jamb mount an HD8000 closer?
That is exactly the case the BP80 backplate covers. Top jamb mounting needs enough frame face to land the closer's fasteners, and under 2-7/8 inches (73 mm) you do not have it. The BP80 plate mounts to the frame and gives the HD8000 closer the mounting surface it needs.
3) How much ceiling clearance do I need above the door for a BP80 top jamb backplate?
Two options are built into the same plate. The BP80 has two sets of mounting holes: one set works with a minimum of 1-3/4 inches (44 mm) of ceiling clearance, the other with 3-1/4 inches (83 mm). Measure from the top of the frame to the ceiling or soffit before you drill, then use the hole set that matches.
4) I have a surface applied overhead stop on the door. Will a top jamb closer clear it?
Use the top set of holes on the BP80. That set creates a drop application, lowering the closer enough to clear a surface applied stop or holder. If your stop or holder is mortised into the frame head instead, mount through the regular set of holes.
5) Will the BP80 backplate work with a door closer from another series or brand?
No. The BP80 is made for the BEST HD8000 series and its hole pattern is cut for that closer. Fitting it to another series or another manufacturer's closer means the mounting holes will not line up. If you are working on a different closer, order that manufacturer's own top jamb bracket or drop plate.
6) Do I need a BP80 backplate or a drop plate for my HD8000 closer?
It depends on which side the closer lands. The BP80 is for top jamb mounting, where the closer body sits on the frame head and the arm goes to the door face; it solves a narrow frame face or a stop in the way. If you are mounting the closer on the door itself (regular or parallel arm) and running short on top rail, a top jamb backplate is the wrong part for that condition.
7) What finishes does the BEST BP80 backplate come in?
Three: 689 aluminum painted, 693 black, and 695 dark bronze painted. These are the standard painted closer finishes, so match the plate to the HD8000 closer body you are installing rather than to the door hardware, since the plate sits directly under the closer at the frame head.
8) Can I standardize on the BP80 across a building where the frames vary?
Yes, and that is the point of the two hole patterns. One part number covers both the 1-3/4 inch (44 mm) and 3-1/4 inch (83 mm) ceiling clearance conditions and both the drop and regular mount cases, so a facility running HD8000 closers can stock a single plate in one finish rather than several brackets.
