BEST BEST CECB1900R-56 Steel Full Mortise Concealed Bearing Standard Weight Electrified Hinge With 6 Wires BEST-CECB1900R-56L-632-4.5x4.5

BEST CECB1900R-56 Steel Full Mortise Concealed Bearing Electrified Hinge with 6 Wires

(No reviews yet) Write a Review

Model: CECB1900R-56L-632-4.5x4.5

In Stock (leaves warehouse same day if ordered before 3pm ET)

$423.23
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST CECB1900R-56 Steel Full Mortise Concealed Bearing Electrified Hinge with 6 Wires

Professional Electrified Hinge Solution for Commercial Access Control

The BEST CECB1900R-56 is a standard weight electrified hinge engineered for commercial door applications requiring integrated electronic access control. This steel construction full mortise hinge features concealed bearings for smooth operation and a 6-wire configuration that conducts current regardless of door position to electric locks, exit devices, or hold open devices. The concealed electric design ensures no electrical parts are exposed when installed, providing tamper-proof operation for secure access control systems.

Professional Features & Benefits

  • 6-Wire Configuration: Streamlined wiring solution with 6 concealed wires for simplified integration with electronic access control systems and reduced installation complexity.
  • Concealed Electric Design: No electrical parts exposed when installed, providing tamper-proof operation and enhanced security for access control applications.
  • Continuous Current Conduction: Conducts current regardless of door position to electric locks, exit devices, or hold open devices for reliable system operation.
  • Steel Construction: Durable steel construction with concealed bearings ensures smooth operation and long-term reliability in commercial applications.
  • Full Mortise Design: Standard weight full mortise configuration with permanent fast pin for secure installation in commercial door frames.
  • Center Hinge Installation: Designed for center hinge location installation to optimize electrical connectivity and door operation.
  • Junction Box Compatible: Should be used along with a junction box for proper electrical connections and code compliance.
  • Complete Installation Package: Packed with all machine screws and installation instructions for professional installation.

Technical Specifications

  • Bearing Type: Concealed Bearing
  • Commercial/Residential: Commercial
  • Corner Style: Square Corners
  • Department: Door Hardware
  • Duty Level: Medium Duty
  • Electronic: Yes
  • Hinge Type: Electrified
  • Knuckles: 3
  • Lock Type: Mortise
  • Number of Wires: 6
  • Product Category: Door Hinges and Pivots
  • Product Finish: Satin Stainless Steel
  • Product Group: Door Hinges and Pivots
  • Product Model: CECB1900R-56
  • Product Subgroup: Electrified Hinges
  • Product Type: Electrified Hinges
  • Series: Electrified Hinges
  • Subcategory: Hinges

Installation & Operation

  1. Verify electrical requirements and confirm compatibility with existing access control system voltage and current specifications.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the hinge in the center hinge location ensuring proper door and frame preparation for full mortise installation with concealed bearings.
  4. Route and connect the 6 concealed wires through appropriate junction box according to manufacturer wiring diagrams and access control system requirements.
  5. Configure operational settings for integration with electric locks, exit devices, or hold open devices per application requirements.
  6. Restore power and test all functions including continuous current conduction throughout door operation and integration with connected access control systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Access Control Systems
  • Healthcare Facility Security Integration
  • Educational Institution Electronic Access
  • Government and Municipal Building Security
  • Corporate Office Electronic Door Control
  • Multi-Tenant Residential Access Systems
  • Industrial Facility Controlled Access Points

Why Choose BEST Quality?

BEST electrified hinges deliver professional-grade reliability with steel construction and concealed bearing design engineered for demanding commercial access control applications. The CECB1900R-56 model provides tamper-proof operation with no exposed electrical components and continuous current conduction regardless of door position. Engineered for commercial applications where dependable electronic access control integration is essential.

Product Specs

Subcategory:
Hinges
Series:
Electrified Hinges
Hinge Type:
Electrified
Knuckles:
3
Bearing Type:
Concealed Bearing
Corner Style:
Square Corners
Product Group:
Door Hinges and Pivots
Product Subgroup:
Electrified Hinges
Product Type:
Electrified Hinges
Number of Wires:
6
Duty Level:
Medium Duty
Commercial/Residential:
Commercial
Electronic:
Yes
Lock Type:
Mortise
Product Model:
CECB1900R-56
Product Finish:
Satin Stainless Steel
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

BEST CECB1900R-56L-632-4.5x4.5 – Frequently Asked Questions

1) Do I have to specify handing when ordering the BEST CECB1900R-56 electrified hinge?
Yes, handing is a required selection. The CECB1900R-56 is ordered left hand or right hand, because the wire exit and the concealed electric raceway have to land on the hinge side of the opening. Get the handing wrong and the wire harness comes out on the wrong face.
2) What size does the BEST CECB1900R-56 electrified hinge come in?
One size: 4-1/2 by 4-1/2 inches with square corners. That is the standard commercial full mortise hinge footprint, so it drops into an existing 4-1/2 inch square corner frame and door prep without router work.
3) Where in the door should the electrified hinge go if I have three hinges on the opening?
Put it in the center hinge location. The CECB1900R-56 is built for that position to keep the wire run short and out of the way of the top and bottom hinges, which stay as standard non-electric hinges. It also should be paired with a junction box in the frame for the field connections.
4) How many wires does the BEST CECB1900R-56 have, and is that enough for an electric strike plus a request-to-exit signal?
Six concealed wires. Six conductors typically covers one power load plus a monitoring or signal circuit, for example an electric lock or exit device power pair with door position or latch monitoring on the remaining conductors. If your device schedule needs more than six conductors through the hinge, step up to an 8-wire transfer such as the Detex EWH8 Series 4-1/2 by 4-1/2 electric hinge.
5) Is a concealed bearing hinge heavy-duty enough for a busy commercial entry?
It is rated medium duty, standard weight, with concealed bearings and a three knuckle full mortise body. That suits normal-traffic commercial interior and tenant doors. For a high-traffic or heavy door, a heavier electric hinge or a continuous geared power transfer hinge is the better call, such as the SDC PTH Series, which we hold with an 800,000 cycle rating.
6) I need more than 6 conductors through the door for a mortise lock with monitoring. What should I use instead of the CECB1900R-56?
Step up to the Detex EWH8 Series five knuckle electric hinge, 4.5 inch by 4.5 inch, which is an 8-wire hinge in satin chrome. The BEST CECB1900R-56 is fixed at 6 wires, so if your device stack needs eight conductors - for example a solenoid pair plus latch and door position monitoring - the EWH8 gives you the extra two without a second transfer device. Note the EWH8 is a five knuckle hinge where the CECB1900R-56 is a 3 knuckle hinge, so the frame and door knuckle pattern will differ from an existing 3 knuckle opening.
7) The CECB1900R-56 is medium duty. What electrified hinge should I use on a high-cycle opening?
For high-traffic openings look at the SDC PTH Series electrified power transfer hinges, which carry an 800,000 cycle rating. The BEST CECB1900R-56 is rated medium duty, which suits typical commercial office, education, and healthcare doors, but a heavily cycled entry or corridor door is where a published cycle rating like the PTH Series is worth specifying. The Securitron EH Series is also offered as a double duty electric hinge for that kind of service.
8) Is the wiring exposed once the hinge is installed?
No. The CECB1900R-56 is a concealed electric hinge, so no electrical parts show when the door is hung and shut. For a facility where tampering at the opening is a concern, that is the reason to use a hinge transfer instead of a surface-mounted door loop.
9) Does current keep flowing when the door is open, or only when it is closed?
Current is conducted regardless of door position. That matters for maglocks, electric latch retraction exit devices, and electric hold-opens that need power while the door swings, and for monitoring circuits that have to report continuously.
10) What comes in the box with the BEST electrified hinge?
The hinge is packed with all machine screws and installation instructions. You still supply the junction box, the wire from the box back to the power supply or access control panel, and any low-voltage conduit the job requires.
11) Can I use the CECB1900R-56 electrified hinge on a door with a half mortise or surface applied frame prep?
No. It is a full mortise hinge, meaning both leaves mortise into the door edge and the frame rabbet. A hollow metal or wood frame with standard hinge pockets is what it needs. If your frame is not prepped for a mortise leaf, a surface-mounted power transfer device is the right approach instead.
12) What is a simpler standard weight electrified hinge alternative in the same 4-1/2 by 4-1/2 size?
The Design Hardware ETW2-BB5 is a 4.5 inch by 4.5 inch electrified standard weight ball bearing hinge in the BB5 Series, rated medium duty. It matches the BEST CECB1900R-56 on size class and medium duty rating, and like the BEST it is a standard weight electrified hinge. The ETW2-BB5 uses a ball bearing, while the CECB1900R-56 uses a concealed bearing and is finished in satin stainless steel with square corners.
13) Is the Securitron EH a drop-in replacement for the BEST CECB1900R-56?
Not a guaranteed drop-in. The Securitron EH is a double duty electric hinge in the EH Series and serves the same purpose - transferring power through the door to an electric lock or exit device - but it is a different manufacturer's hinge, so knuckle pattern, leaf prep, and wire count need to be confirmed against what is already in the frame. The BEST CECB1900R-56 is a 3 knuckle full mortise hinge with 6 wires, square corners, and a concealed bearing. If you are replacing an existing CECB1900R-56 and want the door and frame prep to match without rework, stay with the same 3 knuckle 6-wire configuration.
14) Which of these electrified hinges do I pick if I want the wiring completely hidden and tamper resistant?
The BEST CECB1900R-56 is the concealed electric design in this group - no electrical parts are exposed once the hinge is installed, and it conducts current regardless of door position. It mounts at the center hinge location as a full mortise hinge and should be used with a junction box. Comparable options such as the SDC PTH Series power transfer hinges and the Securitron EH double duty electric hinge perform the same power transfer role but are specified around their own criteria, such as the PTH Series 800,000 cycle rating.
15) What finish is the BEST CECB1900R-56 and will it match my other door hardware?
Satin stainless steel. On a commercial opening that reads alongside satin chrome and brushed stainless lever trim and closers. If your existing electric hinge is satin chrome, the Detex EWH8 is carried in that finish.
