Bolts 10-32 X 2 Hx Ms SS (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Dimensional Standard:
- ASME B18.6.3-2002
- Division:
- Electrical H1
- Drive Type:
- Slotted
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.305 - 0.312 in.
- Fastener Height:
- 0.105 - 0.120
- Fastener Length:
- 2
- Fastener Width:
- 0.34
- Language Code:
- EN
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 3.6 in
- Product Length:
- 3 in
- Product Weight:
- 726 g
- Product Width:
- 76.2 MM
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 32
- Thread Pitch:
- 0.19
- Thread Standard:
- ANSI/ASME B1.1
- Thread Type:
- UNF
- Washer Od:
- 0.384 - 0.414 in.
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- JHHMS
- Product Details:
- Hexagonal Bolt
- Product Material:
- Stainless Steel
Metallics JHHMS35SS – Frequently Asked Questions
1) Will a 10-32 x 2 inch hex machine screw thread into a standard 10-32 tapped box or panel?
Yes. The Metallics JHHMS35SS is a 10-32 machine screw with 32 threads per inch, cut to the ANSI/ASME B1.1 thread standard, so it mates with any 10-32 tapped hole, including the 10-32 ground and device holes common in steel boxes, panel rails and enclosures. At 2 inches of length it is meant for stacking through brackets, spacers or multiple layers rather than a single thin wall.
2) Do these screws meet Buy American and ARRA requirements for a federal or publicly funded job?
The JHHMS35SS 10-32 machine screw is flagged compliant for both ARRA and Buy American in Metallics' product data, which is what a government or institutional procurement file normally needs on a fastener line item. Country of origin is China.
3) Are these Metallics 10-32 machine screws stainless steel, and can they be used outdoors or in damp locations?
They are stainless steel, which is why they get specified for wet, damp and corrosive locations where a plated steel screw would rust out. The screws are made in China.
4) What head and driver do the JHHMS35SS screws take, hex or slotted?
Both. The head is a slotted hex, so you can run it with a 5/16 inch nut driver or socket on the hex, or back it off with a flat blade screwdriver in the slot when there is no room to swing a driver. Head width across flats is 0.305 to 0.312 inch and head height is 0.105 to 0.120 inch.
5) What washer size should I pair with these 10-32 hex machine screws?
A washer with an outside diameter of 0.384 to 0.414 inch suits these 10-32 screws, which is a standard No. 10 flat washer. That OD is wider than the 0.305 to 0.312 inch hex head, so the washer carries the load rather than the head edge, which matters on sheet metal and on slotted strut or bracket holes.
6) How many 10-32 x 2 screws come in a jar, and is there an order minimum?
They ship 100 to a jar, and 100 count is the order minimum, so a single jar is the smallest buy. Jar weight is 726 g. Metallics offers other sizes and quantities in the JHHMS series on request.
7) Is a 10-32 x 2 inch machine screw the same thing as a bolt, and what is it right for?
It is a machine screw with a hex head, dimensioned to ASME B18.6.3-2002, the machine screw standard, not a hex cap bolt standard. Practically that means a uniform 2 inch thread for a tapped hole or a nut, not a shouldered bolt with a grip length. Use it where you need to pull two or three layers of sheet metal, a bracket, or a standoff together into a 10-32 tapped hole. If you need shear strength through an unthreaded hole in structural steel, a hex cap screw is the right part instead.
8) Is the 10-32 thread on these Metallics screws coarse or fine?
Fine. The thread is UNF at 32 threads per inch, with a 0.19 thread pitch listed. That matters if you are matching existing hardware: 10-24 coarse nuts will not run onto these, so order 10-32 nuts or use a 10-32 tapped hole.
