Bolts 1/2-13 X 1-1/4 Hx Tap Blt Galv (Jar 50)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Division:
- Electrical H1
- Fastener Head Height:
- Nov-32 in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.725 - 0.7500 in.
- Fastener Height:
- 0.302 - 0.364
- Fastener Length:
- 1/1/04
- Fastener Width:
- 0.826 - 0.866
- Hardness:
- Rockwell B69-B100
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_Galv_St.pdf
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- EA
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 2132 g
- Product Width:
- 88.9 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 60000 psi minimum
- Thread Per Inch:
- 13
- Thread Standard:
- IFI-199 (2014)
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- HTB, JHTB, and JSHTB
- Product Finish:
- Galvanized
- Product Details:
- Hexagonal Bolt
- Product Material:
- Steel
Metallics JHTBG64 – Frequently Asked Questions
1) What thread does the Metallics JHTBG64 hex tap bolt use, and will it take a standard 1/2-13 nut?
The JHTBG64 is a 1/2-13 hex tap bolt, meaning 1/2 inch diameter with 13 threads per inch, which is standard UNC coarse thread. Any standard 1/2-13 UNC nut or tapped 1/2-13 hole will accept it. Threads are made to IFI-199 (2014).
2) Is a hex tap bolt threaded all the way to the head, or does it have a shoulder like a hex cap screw?
A tap bolt is fully threaded to the head, which is what separates it from a partially threaded hex cap screw. That matters when you are threading into a tapped hole or a channel nut and need engagement right up under the head. The JHTBG64 is 1/2-13 x 1-1/4 inch, so with full thread you get usable engagement through the whole grip.
3) Do Metallics hex tap bolts meet Buy American requirements for a federal or public job?
The JHTBG64 is flagged as both Buy American compliant and ARRA compliant, which is what a government, school district or transit procurement office needs on the submittal. Country of origin is listed as multiple.
4) Can I use these galvanized hex tap bolts outdoors or in a damp electrical room?
The JHTBG64 is galvanized steel, so it holds up in damp and outdoor conditions far better than plain finished steel. Galvanized is the common choice for strut, conduit support and exterior structural anchoring. For continuous saltwater exposure, stainless is the better call.
5) How many bolts come in a jar of Metallics JHTBG64, and is there an order minimum?
They ship 50 bolts to a jar, and the order minimum is 50 each, so one jar is the smallest buy. Metallics offers other sizes and quantities in the HTB, JHTB and JSHTB tap bolt series by request.
6) Will a 1-1/4 inch long bolt be long enough for my application?
At 1-1/4 inch of overall length, fully threaded, the JHTBG64 suits thin assemblies: strut to bracket, two pieces of channel, a clamp onto a plate. Add up your material thickness plus any washers and leave a couple of threads past the nut. If your stack is much over an inch, step up to a longer length in the same tap bolt series rather than forcing this one.
