Bolts 3/4-10 x 3-1/2 HXBT SS (Box 25)
Additional Notes
- Other sizes and quantities available by request
Features
- The molybdenumcontent gives this type of stainless even greater corrosion resistance than 18-8 as well as superior strength at high temperatures.
- 18-8 and 316 stainless steel cap screws are both made from austenitic alloy
Manufacturer Resources
Product Specs
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Division:
- Electrical H1
- Fastener Head Height:
- 15/32 in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 1.100 - 1.125 in.
- Fastener Height:
- 0.455 - 0.483
- Fastener Length:
- 3/1/02
- Fastener Width:
- 1.254 - 1.299
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Hardness:
- Rockwell B80-C32
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Bolt_Dom_18-8_SS_316_SS.pdf
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- EA
- Outside Diameter:
- 0.7410 - 0.7500 IN
- Pack Type:
- Box
- Product Group:
- Fasteners
- Product Height:
- 6 in
- Product Length:
- 7.25 in
- Product Weight:
- 12043 g
- Product Width:
- 158.75 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 85000 - 140000 psi minimum
- Thread Per Inch:
- 10
- Wrenching Height:
- 0.324
- Yield Strength:
- 45000 psi minimum
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- SBHC and JSBHC
- Product Details:
- Hexagonal Bolt
- Product Material:
- 316 Stainless Steel
Metallics SBH760 – Frequently Asked Questions
1) How strong is a 316 stainless 3/4-10 hex bolt like the Metallics SBH760?
Tensile strength is 85,000 to 140,000 psi minimum with a 45,000 psi minimum yield, and hardness falls in the Rockwell B80 to C32 range. That is austenitic stainless territory, not alloy-steel Grade 5 or Grade 8 territory, so if a drawing calls for a heat-treated high-strength bolt, this is not a substitute. Where the spec is corrosion resistance, it is.
2) Are Metallics SBH760 stainless bolts Buy American or ARRA compliant for a government job?
No. The SBH760 is not Buy American compliant and is not ARRA compliant, and country of origin is listed as multiple. If your project carries a domestic-sourcing clause, this bolt will not satisfy it and you need a domestic-marked stainless fastener instead.
3) What size wrench or socket fits the head of the Metallics SBH760 hex bolt?
Head width across flats runs 1.100 to 1.125 inch, so a 1-1/8 inch wrench or socket is the fit. Head height is 15/32 inch, with 0.324 inch of wrenching height, so you need roughly that much clear depth around the head for a socket to seat.
4) Do Metallics SBH760 bolts come as a box or loose, and is there an order minimum?
They ship in a box of 25. The order minimum is 50 each, so a single box will not clear it, two boxes will. Other sizes and quantities in the series are available by request.
5) What trades use the Metallics SBHC series stainless hex bolts?
The SBHC and JSBHC series is aimed at the electrical, plumbing, and heating and air conditioning trades. Typical use is anchoring strut, hangers, trapeze supports, equipment feet, and rooftop or mechanical-room mounting where a plated bolt would rust out.
6) Is the Metallics SBH760 fully threaded, and how much grip length do I have?
It is a 3/4-10 by 3-1/2 inch hex bolt (hex bolts in this length are typically partially threaded, not thread-to-head). Measure your total clamped stack and keep it under 3-1/2 inches of usable length, allowing for a nut and washers, since the bolt head adds 15/32 inch above the surface.
