Bolts 3/8-16 x 1-3/4 HXBT Pln-St (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Division:
- Electrical H1
- Fastener Head Height:
- 4-Jan in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.544 - 0.562 in.
- Fastener Height:
- 0.226 - 0.268
- Fastener Length:
- 1/3/04
- Fastener Width:
- 0.620 - 6.650
- Language Code:
- EN
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Outside Diameter:
- 0.360 - 0.388 IN
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 7.25 in
- Product Length:
- 4.5 in
- Product Weight:
- 6.41 lbs
- Product Width:
- 4.5 in
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 16
- Thread Standard:
- ASME B18.2.1-1996
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- BHC and JBHC
- Product Finish:
- Plain
- Product Details:
- Hexagonal Bolt
- Product Material:
- Steel
Metallics JBHC60PL – Frequently Asked Questions
1) Is the Metallics JBHC60PL bolt plated or coated for outdoor use?
No. The finish is plain steel, meaning bare and uncoated. That's fine for dry interior work, indoor strut runs, and panel mounting, but it will rust outdoors, in damp mechanical rooms, or anywhere washdown happens. For exterior or wet locations choose a zinc plated or hot dip galvanized 3/8-16 bolt instead.
2) How many bolts come in a jar of Metallics JBHC60PL?
100 pieces per jar, and 100 count is the order minimum, so the jar is the base unit. The packed jar weighs 6.41 lbs. Jar packaging suits a service van or a shop crib where you're pulling a handful at a time rather than opening a bulk box.
3) Do these Metallics hex bolts meet Buy American requirements on a federal job?
The JBHC60PL is flagged both ARRA compliant and Buy American compliant in the manufacturer data, though country of origin is listed as China. If your specification carries a domestic melt and manufacture clause, verify against the project's exact language before you submit.
4) What dimensional standard do these 3/8-16 hex bolts follow?
Threads and head geometry follow ASME B18.2.1-1996, the inch hex bolt and screw standard. That means the head and thread form interchange with any other B18.2.1 3/8-16 bolt, and standard 3/8-16 nuts and tapped holes will take it.
5) Can I get this 3/8-16 bolt in a different length or a bigger pack?
Yes. Metallics lists other sizes and quantities in the BHC and JBHC bolt series by request, so if 1-3/4 inches is short for your clamp stack or you need bulk rather than a 100 count jar, that can be sourced.
