Bolts 3/8-16 X 3 Hx Tap Blt SS (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Division:
- Electrical H1
- Fastener Head Height:
- 4-Jan in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.544 - 0.562 in.
- Fastener Height:
- 0.226 - 0.268
- Fastener Length:
- 3
- Fastener Width:
- 0.620 - 0.650
- Field Application:
- Complete Thread Engagement Applications, Electrical, Plumbing, Heating, Air Conditioning Industries
- Hardness:
- Rockwell B95-C32
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_St-Zn_and_18-8_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- JR
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 7.25 in
- Product Length:
- 4.5 in
- Product Weight:
- 4191 g
- Product Width:
- 114.3 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 95000 psi minimum
- Thread Direction:
- Right Hand
- Thread Per Inch:
- 16
- Thread Standard:
- IFI-199 (2014)
- Yield Strength:
- 60000 psi minimum
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Tap Bolt
- Type2:
- Hexagonal Tap Bolt
- Series:
- HTB, JHTB, and JSHTB
- Product Details:
- Hexagonal Tap Bolt
- Product Material:
- 18-8 Stainless Steel
Metallics JSHTB26 – Frequently Asked Questions
1) What size and thread is the Metallics JSHTB26 hex tap bolt?
It's a 3/8-16 hex tap bolt, 3 inches long, with right hand threads at 16 threads per inch. Tap bolts are threaded the full length, so the whole 3 inches engages a tapped hole or nut rather than leaving an unthreaded shank.
2) Is the JSHTB26 tap bolt stainless, and will it hold up outdoors or in a wet mechanical room?
The bolt is 18-8 stainless steel, which is the austenitic grade normally specified for damp, washdown, and exterior service where plated carbon steel would rust. Metallics lists it for electrical, plumbing, heating and air conditioning work.
3) How strong is a 3/8-16 stainless tap bolt like this compared to a plated Grade 5?
Rated at 95,000 psi minimum tensile and 60,000 psi minimum yield, with hardness of Rockwell B95 to C32. That is lower than a Grade 5 carbon steel bolt of the same diameter, so if the connection is strength critical rather than corrosion critical, size up or move to a plated high strength bolt. Where moisture is the problem, the stainless is the right trade.
4) Will this bolt meet a Buy American or ARRA requirement on a federal job?
No. The JSHTB26 is not Buy American compliant and is not ARRA compliant, with country of origin listed as multiple. On a federally funded project with domestic sourcing language, this fastener will not satisfy it.
5) How does the JSHTB26 come packaged and what is the minimum order?
Supplied in a jar of 100 pieces, and 100 (one jar) is the minimum order quantity. Metallics notes other sizes and quantities can be had by request.
6) Do these hex tap bolts need nuts, or can they thread into a tapped hole?
Either works. Because the thread runs the full 3 inch length, they can be run straight into a tapped hole, a channel nut, or a strut insert, or used conventionally with a nut and washers. Nuts and washers are not included in the jar of 100 bolts.
7) What thread standard do these Metallics tap bolts follow, so I can mix them with existing hardware?
Threads are produced to IFI-199 (2014), right hand, 3/8-16 UNC. They mate with any standard 3/8-16 nut, insert, or tapped hole already on the job.
8) Which Metallics part number should I order for a stainless 3/8-16 x 3 hex tap bolt?
Order part JSHTB26. It sits in the Metallics HTB, JHTB and JSHTB tap bolt series, where the JSHTB prefix is the jar-packed stainless version.
