Metallics JSBH302 Bolts 5/16-24 x 1-1/4 HXBT SS (Jar 100)

Metallics JSBH302 Bolts 5/16-24 x 1-1/4 HXBT SS (Jar 100)

(No reviews yet) Write a Review

Model: JSBH302
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$52.51
$3.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Bolts 5/16-24 x 1-1/4 HXBT SS (Jar 100)

  • Additional Notes

    • Other sizes and quantities available by request

  • Features

    • 18-8 and 316 stainless steel cap screws are both made from austenitic alloy
    • Used in products that require general atmospheric corrosion resistance, such as chemical and food-processing equipment. Some chemical environments may require special corrosion resistant materials and precautions.

Manufacturer Resources

Product Specs

Arra Compliant:
C
Buy American Compliant:
C
Division:
Electrical H1
Fastener Head Height:
13/64 in.
Fastener Head Type:
Hex
Fastener Head Width:
0.489 - 0.500 in.
Fastener Height:
0.195 - 0.211
Fastener Length:
1/1/04
Fastener Width:
0.557 - 0.577
Hardness:
Rockwell B95-C32
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Bolt_Dom_18-8_SS_316_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Outside Diameter:
0.3065 - 0.3125 IN
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
4.57 in
Product Length:
3 in
Product Weight:
1551 g
Product Width:
76.2 MM
Sub Division:
Electrical-E H2
Tensile Strength:
100000 - 150000 psi minimum
Thread Per Inch:
24
Yield Strength:
65000 psi minimum
Department:
Electrical
Product Subgroup:
Bolts
Product Type:
Hexagonal Bolt
Type2:
Hexagonal Bolt
Series:
SBHC and JSBHC
Product Details:
Hexagonal Bolt
Product Material:
18-8 Stainless Steel

Metallics JSBH302 – Frequently Asked Questions

1) Is the Metallics JSBH302 bolt a coarse or fine thread, and will it work in a 5/16-18 tapped hole?
It is a fine thread: 24 threads per inch, so 5/16-24 UNF. It will not start in a 5/16-18 coarse tapped hole or nut. Match it to 5/16-24 nuts and tapped holes only.
2) Will stainless hex bolts like the JSBH302 hold up outdoors or in a wash-down area?
They are 18-8 stainless, an austenitic alloy used where general atmospheric corrosion resistance is needed, including chemical and food-processing equipment. For aggressive chemical exposure, 316 stainless or another specially selected corrosion resistant material is the better call.
3) What wrench or socket size do I need for these Metallics 5/16-24 hex bolts?
Across the flats the head measures 0.489 to 0.500 inch, so a 1/2 inch wrench or socket is the fit. Head height is 13/64 inch, which matters if you are working in a shallow recess or under a cover plate.
4) How strong is a Metallics 18-8 stainless 5/16-24 hex bolt?
Tensile strength runs 100,000 to 150,000 psi minimum with a 65,000 psi minimum yield, and hardness is Rockwell B95 to C32. That is a general purpose stainless fastener, not a substitute for a Grade 8 alloy bolt in a high-preload structural joint.
5) How many bolts come in a jar of Metallics JSBH302, and can I buy fewer?
They ship as a jar of 100, and 100 count is the order minimum. The jar pack is what makes these practical for a service van or shop bin rather than a single job. Other sizes and quantities are available by request.
6) Do these Metallics stainless bolts meet Buy American or ARRA requirements for a public project?
The JSBH302 is flagged compliant for both Buy American and ARRA. Country of origin is listed as multiple, so if your specification demands a single documented source country, confirm the origin on the lot you receive.
7) What is the actual shank diameter on a 5/16-24 Metallics hex bolt for a clearance hole?
Outside diameter is specified at 0.3065 to 0.3125 inch, so a standard 11/32 inch clearance hole gives room to pass; a 5/16 drilled hole will be a line-to-line fit at best.
8) Can I mix these stainless bolts with galvanized or plated steel parts?
Mechanically yes, in any 5/16-24 tapped hole or nut. Electrically, pairing 18-8 stainless with zinc or galvanized steel in a wet location sets up a dissimilar metal couple and the coating will sacrifice first. For enclosures and strut hardware in damp areas, keep the nut, washer and bolt all stainless.
