Boshart CC-6-CI 6" Cast Iron Well Conduit Cap with Stainless Steel Set Screws

Boshart CC-6-CI 6" Cast Iron Well Conduit Cap with Stainless Steel Set Screws

(No reviews yet) Write a Review

Model: CC-6-CI

In Stock (leaves warehouse same day if ordered before 3pm ET)

$40.05
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Boshart CC-6-CI 6" Cast Iron Well Conduit Cap

The Boshart CC-6-CI is a 6" cast iron conduit well cap built to provide extra clearance for pump cable at the top of a well casing. This cast iron cap secures directly to the well casing with three stainless steel set screws, while a separate stainless steel screw locks down the conduit pipe carrying the pump cable. A well log is included inside each cap so installers can record installation data and well specifications on site, keeping that information with the wellhead for future service calls. This is trade rough-in well equipment intended for licensed well contractors and pump installers, not a decorative or finish-grade fitting.

Key Features

  • Trade Size: 6" cast iron cap sized to fit standard 6" well casing.
  • Durable Construction: Cast iron body provides a rugged, heavy-duty cap for wellhead protection.
  • Casing Attachment: Three stainless steel set screws secure the cap firmly to the well casing.
  • Conduit Retention: A dedicated stainless steel screw secures the conduit pipe that houses the pump cable.
  • Pump Cable Clearance: Cap design is engineered to give extra clearance for pump cable routing at the wellhead.
  • Integrated Well Log: A well log is provided inside each cap to record installation data and specifications for future reference.

Technical Specifications

  • Trade Size: 6"
  • Material: Cast Iron body with stainless steel set screws
  • Country of Origin: Taiwan
  • Packaging: 12 ea per case

Typical Applications

  • Residential and Agricultural Well Installations
  • Wellhead Protection for Submersible Pump Systems
  • Pump Cable and Conduit Routing at the Well Casing
  • New Well Construction and Well Casing Retrofits
  • Rough-In Work by Licensed Well and Pump Contractors

Why Boshart?

Boshart's CC-6-CI conduit well cap combines a durable cast iron body with stainless steel hardware, giving well contractors a rugged cap that stands up to outdoor wellhead exposure while keeping pump cable properly secured and clear. The included well log helps installers document specifications directly at the point of installation, supporting long-term service and maintenance of the well system. Boshart's attention to functional details like cable clearance and secure casing attachment makes this cap a practical choice for professional well and pump installation work.

Manufacturer Resources

Product Specs

list_batch:
BOS-20260923
Product Type:
Cap
Connection Type:
Set Screw
Department:
Plumbing
Product Subgroup:
Caps
Product Material:
Cast Iron
Product Size:
6"
Product Group:
Plumbing Fittings
Product Width:
7.6 in
Product Length:
7.6 in
Product Weight:
4.8 lb
Product Height:
3.15 in

Boshart CC-6-CI – Frequently Asked Questions

1) Will the Boshart CC-6-CI conduit cap fit a 6 inch well casing?
Yes. The CC-6-CI is a 6 inch trade size cap sized to fit standard 6 inch well casing, and it clamps on with three stainless steel set screws rather than threading on. Because it is a set screw attachment, it works on plain-end steel casing cut off at the wellhead without any casing prep.
2) Can I use the CC-6-CI on an existing well, or is it only for new construction?
Both. Boshart lists the CC-6-CI for new well construction as well as well casing retrofits, and the set screw attachment is what makes the retrofit work, you cut in on the existing 6 inch casing and tighten the three screws down. Typical uses are residential and agricultural wells with submersible pumps.
3) What is the difference between a conduit well cap and a standard well cap?
A conduit cap like the CC-6-CI is built to carry the pump cable out of the wellhead inside a conduit pipe instead of just passing it under the cap edge. It has a dedicated stainless steel screw that locks the conduit pipe in place, and the body is shaped to give extra clearance for the pump cable. If you are not running the cable in conduit, you do not need the conduit provision.
4) Is the Boshart CC-6-CI cast iron or plastic?
Cast iron body with stainless steel set screws. That combination is aimed at outdoor wellhead exposure, where the iron takes the abuse and the stainless hardware stays serviceable for future pulls. It is rough-in well equipment for licensed well and pump contractors, not a finish-grade fitting.
5) How does the pump cable stay protected where it leaves the well casing?
The cable runs inside a conduit pipe, and the cap has a separate stainless steel screw that clamps that conduit so it cannot shift. The cap body itself is shaped to leave extra clearance for the cable at the top of the casing, which keeps it off the casing edge where it would otherwise chafe. The conduit pipe is not supplied with the cap.
6) Does the Boshart conduit cap come with anything for recording well data?
Yes, a well log is included inside each CC-6-CI cap. You fill in installation data and well specifications on site, so the record stays at the wellhead for whoever pulls the pump years later.
7) How many Boshart CC-6-CI conduit caps come in a case?
Packaging is 12 each per case. That matters if you are a distributor or a well contractor stocking a truck, single caps and full cases carry the same MPN, CC-6-CI.
