Boshart PG Series 2" Dry Pressure Gauge, No-Lead Lower Mount

Boshart PG Series 2" Dry Pressure Gauge, No-Lead Lower Mount

The Boshart PG Series 2" Dry Pressure Gauge is a general-purpose rough-in and system-monitoring gauge built for plumbers and contractors who need a reliable pressure readout on water distribution and mechanical piping systems. This gauge line features a 2" dry dial case and a 1/4" lower mount (LM) connection, and is available across multiple pressure ranges from 0-15 PSI up to 0-100 PSI (models PG-15NL, PG-30NL, PG-60NL, PG-100NL), making it well suited for low- to moderate-pressure applications where precise, easy-to-read feedback is needed at the point of installation. Every gauge in the PG Series is manufactured to a No-Lead standard, and none are rated for use with oxygen systems - they are intended strictly as general-purpose pressure indicators on water and compatible fluid lines. With its compact 2" dry case and 1/4" lower mount thread, the PG Series gauge threads directly into a tee, boiler drain, or gauge port on the rough-in side of a plumbing or mechanical assembly, giving installers and service techs a quick visual check of system pressure without the added cost or complexity of a liquid-filled gauge. Because it ships in bulk from the factory, this gauge family is a practical stocking item for plumbing wholesalers, mechanical contractors, and service trucks that regularly install or replace gauges on residential and light commercial water systems.

Key Features

• Trade Size: 2" dry dial case with a 1/4" lower mount (LM) connection for direct installation into gauge ports, tees, and boiler drains.
• Pressure Range Options: available in 0-15 PSI, 0-30 PSI, 0-60 PSI, and 0-100 PSI readings (PG-15NL, PG-30NL, PG-60NL, PG-100NL), suited to a wide span of water distribution and monitoring applications.
• Dry Case Design: dry (non-liquid-filled) dial construction for straightforward, economical pressure readouts on general-purpose plumbing lines.
• No-Lead Construction: manufactured to a No-Lead standard for use on potable water-adjacent plumbing systems where lead-free components are specified.
• General Purpose Use Only: rated for general-purpose service - these gauges are NOT approved for use with oxygen systems.
• Lower Mount Connection: 1/4" LM thread positions the gauge for direct in-line or port-mounted installation on rough-in plumbing assemblies.

Technical Specifications

• Series: PG Series
• Case Size: 2" dry dial
• Connection: 1/4" lower mount (LM)
• Pressure Range Options: 0-15 PSI, 0-30 PSI, 0-60 PSI, 0-100 PSI
• Construction: No-Lead
• Country of Origin: China
• Packaging: 100 ea

Typical Applications

• Residential and Light Commercial Rough-In Plumbing Systems
• Water Distribution Pressure Monitoring
• Boiler Drain and Gauge Port Installations
• Service Truck Stock for Pressure Gauge Replacement
• Low- to Moderate-Pressure Mechanical Piping Systems

Why Boshart?

Boshart builds the PG Series pressure gauge line with No-Lead construction and a straightforward dry-case design that plumbing contractors and wholesalers can rely on for consistent, accurate pressure readouts on rough-in and service work. The 1/4" lower mount connection and 2" dry dial make it a simple, drop-in solution for jobs that call for a compact, general-purpose gauge rather than a specialty liquid-filled or oxygen-rated instrument, with a full range of pressure options to match the application. Stocked in case quantities of 100 ea, the PG Series is built for trade professionals who need dependable, code-appropriate gauges on hand for everyday plumbing installations.
