Bridgeport Lock-A-Liners

Bridgeport Fittings Lock-A-Liners Insulating Bushing Conversion System - Black Polypropylene with 150°C Heat Rating

(No reviews yet) Write a Review

Model: BF-191

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.61
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bridgeport Fittings Lock-A-Liners Insulating Bushing Conversion System

Professional Code-Approved Electrical Insulation Solution

Bridgeport Fittings Lock-A-Liners provide a reliable solution for converting ordinary bushings and connectors to code-approved insulating bushings and connectors. This professional-grade system features heat-rated polypropylene construction with NEMA FB-1 rating, delivering dependable electrical insulation performance for demanding applications.

Professional Features & Benefits

  • 150°C Heat Rating: Polypropylene liner lock construction withstands high-temperature environments for reliable long-term performance in demanding electrical applications.
  • NEMA FB-1 Rating: Meets stringent industry standards for insulating bushing applications, ensuring code compliance and professional installation quality.
  • Code Conversion Capability: Transforms ordinary bushings and connectors into code-approved insulating components, providing installation flexibility and compliance assurance.
  • Durable Polypropylene Construction: Plastic material construction delivers excellent electrical insulation properties with resistance to environmental factors.
  • OSHA-Recognized Standards: All Bridgeport fittings meet OSHA-recognized, NRTL-listed electrical standards for professional safety compliance.
  • UL Listed: UL File E11259 certification provides third-party verification of safety and performance standards for professional applications.

Technical Specifications

  • Country Of Origin: United States
  • Department: Electrical
  • Division: Electrical H1
  • Field Application: Used for converting ordinary bushings and connectors to code approved insulating bushings and conne
  • Heat Rating: The polypropylene liner lock construction is heat rated to 150 C
  • Nema Rating: FB-1
  • Product Color: Black
  • Product Finish: Plain
  • Product Material: Plastic
  • Professional Performance: All Bridgeport fittings meet OSHA-recognized, NRTL-listed electrical standards and meet the stringe
  • Sub Division: Electrical-E H2
  • Ul File: E11259

Professional Applications

  • Commercial Electrical Installations
  • Industrial Facility Upgrades
  • Residential Service Panel Modifications
  • Professional Electrical Contracting
  • Code Compliance Retrofits
  • Maintenance and Repair Operations

Why Choose Bridgeport Fittings Quality?

Bridgeport Fittings delivers proven reliability with OSHA-recognized, NRTL-listed electrical standards compliance and UL File E11259 certification. The durable polypropylene construction with 150°C heat rating and NEMA FB-1 rating ensures dependable performance in professional electrical applications.

Manufacturer Resources

Product Specs

Country Of Origin:
United States
Department:
Electrical
Division:
Electrical H1
Nema Rating:
FB-1
Product Color:
Black
Product Finish:
Plain
Product Material:
Plastic
Sub Division:
Electrical-E H2
Certifications:
E11259
Product Type:
Conduit Bushing
Product Subgroup:
Conduit Fittings
Product Group:
Conduit & Raceway

Bridgeport Fittings BF-191 – Frequently Asked Questions

1) What does a Bridgeport Lock-A-Liner actually do on a metal bushing?
It snaps into an ordinary bushing or connector and lines the throat with insulating polypropylene, turning that fitting into a code-approved insulated bushing or connector. That is the whole point of the part: instead of pulling the metal fitting and replacing it with an insulated-throat version, you add the liner. It carries a NEMA FB-1 rating and is UL listed under file E11259.
2) What trade sizes do Bridgeport Lock-A-Liners come in?
Six sizes, matched to conduit trade size: 1/2 inch (191), 3/4 inch (192), 1 inch (193), 1-1/4 inch (194), 1-1/2 inch (195) and 2 inch (196). Order the liner to the trade size of the bushing or connector it is going into, not to the wire size.
3) Inspector flagged my conduit terminations for missing insulated throats. Can I fix that without redoing the fittings?
That is the retrofit this part exists for. Adding a Lock-A-Liner to the existing bushing or connector converts it to a code-approved insulating bushing or connector, so the metal fitting and the conduit stay in place. It is UL listed under file E11259 and rated NEMA FB-1, which is the standard that covers insulating bushings, so the corrected termination is documentable.
4) Will a plastic liner hold up at panel and gutter temperatures?
The polypropylene liner lock construction is heat rated to 150 C, so it is intended for high-temperature electrical enclosures and raceway terminations rather than just cool interior work. Material is plastic, colored black with a plain finish.
5) Are Bridgeport Lock-A-Liners acceptable for commercial and industrial inspection, or residential only?
They are used across commercial electrical installations, industrial facility upgrades, residential service panel work, and code compliance retrofits. All Bridgeport fittings meet OSHA-recognized, NRTL-listed electrical standards, and this liner carries UL file E11259 plus a NEMA FB-1 rating.
6) Where are Bridgeport Lock-A-Liners made? I have a domestic-sourcing requirement on the job.
Country of origin is the United States, which is what public and institutional buyers with domestic preference clauses need on record.
7) I need to stock these for an MRO crib. What is the part numbering so I can standardize?
The numbering runs straight up with trade size: 191 is 1/2 inch, 192 is 3/4 inch, 193 is 1 inch, 194 is 1-1/4 inch, 195 is 1-1/2 inch, 196 is 2 inch. Same black polypropylene liner across all six, so one bin per size covers most bushing and connector terminations a maintenance crew touches.
