Bryant 30103D 103D Series 600V...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$173.70
Bryant 30103D 103D Series 600V 3-Pole Manual Disconnect Switch

Bryant 30103D 103D Series 600V 3-Pole Manual Disconnect Switch

(No reviews yet) Write a Review

Model: 30103D

In Stock (leaves warehouse same day if ordered before 3pm ET)

$173.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bryant 30103D 103D Series 600V 3-Pole Manual Disconnect Switch

The Bryant 30103D 103D Series 600V 3-Pole Manual Disconnect Switch delivers dependable manual disconnect capability for demanding three-phase electrical systems. Rated for 600V service with a 3-pole configuration, this switch safely isolates three-phase circuits during maintenance, inspection, or emergency shutdown, and is available in Motor FLA ratings of 30A and 40A to match your motor load requirements and provide flexible circuit protection across a range of applications. Built to the quality standards Bryant electrical products are known for, the 103D Series is a practical choice for commercial and industrial power distribution applications where dependable, code-compliant circuit isolation is required for panelboards, switchgear, and motor control installations.

Key Features

  • Model Designation: Bryant 103D Series disconnect switch, model 30103D, for easy identification and specification across commercial projects.
  • Voltage Rating: Rated for 600V service, suitable for higher-voltage commercial and industrial circuits and equipment feeders.
  • 3-Pole Configuration: Three-pole design enables simultaneous switching of all three conductors in a three-phase circuit for complete isolation.
  • Motor FLA Options: Available in Motor FLA ratings of 30A and 40A, allowing the switch to be matched to the connected motor's full-load amperage and application requirements.
  • Manual Disconnect Function: Provides a visible, lockable point of isolation for safely de-energizing circuits during service, inspection, or maintenance.
  • Bryant Build Quality: Manufactured by Bryant, a recognized name in professional-grade electrical distribution equipment for demanding environments.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Commercial and Industrial Electrical Distribution
  • Three-Phase Motor and Equipment Circuits
  • Panelboard and Switchgear Isolation Points
  • Maintenance and Service Disconnect Applications
  • New Construction and Electrical Retrofits

Why Bryant?

Bryant has long been a trusted name in electrical distribution products for demanding commercial and industrial environments. The 103D Series 600V 3-Pole Disconnect Switch, available in 30A and 40A Motor FLA ratings, reflects that standard, offering dependable three-pole switching built for professional installations that require reliable manual isolation. Choosing Bryant means specifying equipment designed for reliable, code-compliant performance in critical power distribution applications where safety and dependable circuit isolation are essential.

Manufacturer Resources

Bryant Full Line Catalog

Product Specs

list_batch:
BRY-20260909
Product Type:
Disconnect Switch
Voltage Rating:
600V
Configuration:
3-Pole
Series:
103D Series
Amperage Rating:
30A-40A
Department:
Electrical
Product Group:
Power Distribution
Product Subgroup:
Safety Switches & Disconnects

Bryant 30103D – Frequently Asked Questions

1) Will the Bryant 103D disconnect switch work on a 480V three-phase motor circuit?
Yes. The Bryant 103D Series manual disconnect is rated 600V, so it covers the common 208V, 240V and 480V three-phase systems. Its 3-pole build switches all three ungrounded conductors at once, which is what you need for complete isolation on a three-phase feeder or motor circuit.
2) What is the difference between the Bryant 30103D and the 40003D?
Both are the same 600V 3-pole manual disconnect; the difference is the motor full-load-amp rating. Order 30103D for a 30A motor FLA and 40003D for 40A. Size it against the nameplate FLA of the motor you are isolating, not the breaker size.
3) Does the Bryant 103D include fuses or overcurrent protection?
No. The 103D Series is a non-fused manual disconnect switch, so it isolates the circuit but provides no overcurrent protection on its own. If you need fusing built into the disconnect, a fusible unit such as the Square D TeSys GS 3-pole 30A 600V fuse disconnect switch is the type to look at instead.
4) What is the closest equivalent to the Bryant 30103D if I need fusing built into the disconnect?
The Bryant 30103D is a 3-pole manual disconnect switch rated 600V, sized by Motor FLA at 30A and 40A. It switches the three phases but does not carry fuses. If the circuit needs overcurrent protection at the same device, the Square D TeSys GS1DU3 is a fuse disconnect switch, 3-pole, 30A, 600V, so it matches the pole count and voltage class while adding fuse holders in the same enclosure position. Choose the Bryant where upstream fusing or breaker protection already exists and you only need a service isolation point.
5) Can this Bryant disconnect be locked out for maintenance?
Yes, the 103D Series is a manual disconnect that gives a visible, lockable point of isolation for de-energizing a circuit during service or inspection, so it can be used as the local service disconnect at a motor or piece of equipment.
6) I need a rotary handle disconnect that mounts through an enclosure door. Is this the right one?
The Bryant 103D is a manual disconnect switch without a door-mounted rotary operator. For a through-the-door rotary handle arrangement, the Square D TeSys VLS protruding rotary handle disconnect switch with the 65 x 65 mm handle is the style to specify.
7) Is a 40A disconnect enough for a 40A motor, or should I go larger?
The 40003D is rated at 40A motor FLA, which means it is matched to a motor drawing up to 40 amps full load. Compare it to the motor nameplate FLA. If the nameplate is above 40A, neither the 30A nor the 40A version in the 103D Series covers it and you need a higher-amperage disconnect.
8) I need a disconnect operated from outside the enclosure door. Is the Bryant 103D the right choice?
The Bryant 103D Series, models 30103D and 40003D, is a manual disconnect switch providing a lockable point of isolation for three-phase 600V circuits. If the requirement is a door-mounted operator the electrician turns from the front of the panel, the Square D TeSys VLSH2S5B is a protruding rotary handle disconnect switch with a 65 x 65 mm handle, which is the format used when the handle must break the enclosure face. Specify the Bryant when the switch sits inside the assembly or in its own housing and the rotary handle format is not required.
9) Where is the Bryant 103D switch typically used in a building's power distribution?
Typical placements are panelboard and switchgear isolation points, three-phase motor and equipment branch circuits, and service disconnects for maintenance, in both new construction and retrofit work. It is a commercial and industrial distribution device rather than a residential wall switch.
How fast can I get the Bryant 30103D delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Bryant 30103D come with a warranty?
Absolutely. The Bryant 30103D is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Bryant 30103D?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Bryant 30103D from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
!
