Bussmann 170H3005 Eaton Series High-Speed Fuse Microswitch

Bussmann 170H3005 Eaton Series High-Speed Fuse Microswitch

(No reviews yet) Write a Review

Model: 170H3005

In Stock (leaves warehouse same day if ordered before 3pm ET)

$663.34
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170H3005 Eaton Series High-Speed Fuse Microswitch

The Bussmann 170H3005 Eaton series high-speed fuse microswitch is a fuse accessory engineered to monitor fuse status on high-speed fuses used in demanding power distribution, motor protection, and semiconductor protection circuits. Rated 700V (UL) / 690V (IEC) at 630A, this single-pole microswitch mounts to DIN 43653 fuse bases and is UL 512 certified and RoHS compliant, making it a reliable accessory for professional electrical and industrial installations where fuse-state indication is required.

Key Features

  • Voltage & Amperage Rating: Rated 700V (UL) / 690V (IEC) at 630A, suitable for high-speed fuse monitoring in industrial power circuits.
  • DIN 43653 Mounting: Built to the DIN 43653 standard for direct fitment to compatible high-speed fuse bases.
  • Single-Pole Configuration: Single-pole microswitch design provides straightforward fuse-state monitoring in a compact accessory.
  • Fixed Mounting Position: No swivelling mechanism, delivering a fixed, stable mounting orientation once installed.
  • Compact, Defined Dimensions: Measures 217 mm (length/depth) x 94 mm (width) x 82 mm (height) and weighs approximately 1027 g.
  • UL 512 Certified: Certified to UL 512 for recognized electrical safety compliance.
  • RoHS Compliant: Manufactured to meet RoHS compliance requirements for restricted substances.

Certifications & Compliance

  • UL 512 Listed
  • RoHS Compliant

Technical Specifications

  • Amperage Rating: 630 A
  • Voltage Rating: 700 V (UL), 690 V (IEC)
  • Certifications: UL 512
  • Compliances: RoHS Compliant
  • Mounting Method: DIN 43653
  • Number Of Poles: Single-pole
  • Swivelling Mechanism: No
  • Product Height: 82 mm
  • Product Length Depth: 217 mm
  • Product Width: 94 mm
  • Product Weight: 1027 g
  • Item Quantity: 1

Typical Applications

  • High-Speed Fuse Monitoring in Industrial Power Distribution
  • Motor and Semiconductor Protection Circuits
  • Panelboards and Switchgear Requiring Fuse-State Indication
  • OEM Equipment Built Around DIN 43653 Fuse Accessories
  • Commercial and Industrial Electrical Installations

Why Bussmann?

Bussmann by Eaton is a long-trusted name in circuit protection, and the 170H3005 microswitch reflects that standard with UL 512 certification and RoHS-compliant construction. Its DIN 43653 mounting and 700V (UL) / 690V (IEC), 630A rating make it a dependable accessory for pairing with high-speed fuses in professional, code-compliant electrical systems.

Manufacturer Resources

Product Specs

Amperage Rating:
630 A
Certifications:
UL 512
Compliances:
RoHS Compliant
Mounting Method:
DIN 43653
Number Of Poles:
Single-pole
Product Height:
82 mm
Product Length Depth:
217 mm
Product Weight:
1027 g
Product Width:
94 mm
Swivelling Mechanism:
No
Voltage Rating:
700 V (UL), 690 V (IEC)
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Other Fuses
Product Type:
Fuse accessory
Product Details:
Fuse accessory
Item Quantity:
1
