Bussmann 170M-313 High-Speed Square Body Fuse, Class aR, 63A, 100kAIC

Bussmann 170M-313 High-Speed Square Body Fuse, Class aR, 63A, 100kAIC

(No reviews yet) Write a Review

Model: 170M3139

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,023.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M-313 High-Speed Square Body Fuse, Class aR, 63A, 100kAIC

Eaton Bussmann brings the 170M-313 High-Speed Square Body Fuse to demanding power electronics applications, engineered as a Class aR fuse for accompanied semiconductor protection. Rated 1250V (IEC) and 1300V (UL) with a 63A current rating and 100 kAIC interrupt rating, this DIN 43 620 square body fuse features a top fuse status indicator for quick visual verification of fuse condition. Built for high-speed operation, it is designed to help protect sensitive power semiconductor devices in industrial and commercial electrical systems.

Key Features

  • Compact Dimensions: Square body fuse measuring 65 mm height x 145 mm width x 305 mm length/depth for standardized panel and fuse-holder integration.
  • Square Body Design: Square body construction with slotted center bolted tags per the Fuse Shape specification, delivering secure, low-resistance connections in line with DIN 43 620.
  • Dual Voltage Rating: Rated 1250V (IEC) and 1300V (UL), supporting both international and North American power electronics standards.
  • 63A / 100 kAIC Rating: 63A current rating paired with a 100 kAIC interrupt rating for high fault-current withstand in demanding applications.
  • Class aR Protection: Utilization Category aR (accompanied semiconductor protection), designed to protect power semiconductor devices when coordinated with appropriate branch-circuit protection.
  • Top Fuse Status Indicator: Built-in top indicator allows quick visual identification of a blown fuse without removal from the holder.
  • DIN 43 620 Standard: Manufactured to the DIN 43 620 dimensional standard for compatibility with standard square body fuse holders.

Certifications & Compliance

  • CE Marked

Technical Specifications

  • Packaging Type: Standard
  • Product Height: 65 mm
  • Product Width: 145 mm
  • Product Length/Depth: 305 mm
  • Utilization Category: aR (accompanied semiconductor protection)
  • Insulated Metal Gripping Lugs (IMGL): No
  • Compliances: CE Marked
  • Fuse Shape: Square body, slotted center bolted tags

Typical Applications

  • Power Semiconductor Protection
  • Variable Frequency Drives and Motor Controls
  • Industrial Power Electronics
  • Rectifier and Converter Circuits
  • Panelboard and Switchgear Protection

Why Bussmann?

Eaton Bussmann is a trusted name in circuit protection, and the 170M-313 square body fuse reflects that reliability with a DIN 43 620 compliant design, CE marking, and a 100 kAIC interrupt rating built for demanding semiconductor protection duty. The dual IEC/UL voltage rating and top fuse status indicator make it a practical choice for professional electrical work where fast, code-compliant fault protection is essential.

Manufacturer Resources

Product Specs

Interrupt Rating:
100 kAIC
Department:
Electrical
Product Details:
Fuse
Fuse Indicator:
Top fuse status indicator
Mounting Method:
DIN 43 620
Packaging Type:
Standard
Voltage Rating:
1250V
Product Height:
65 mm
Product Subgroup:
Other Fuses
Class:
Class aR
Utilization Category:
aR (accompanied semiconductor protection)
Product Group:
Fuses
Product Type:
Fuse
Insulated Metal Gripping Lugs Imgl:
No
Product Width:
145 mm
Compliances:
CE Marked
Product Length Depth:
305 mm
Fuse Shape:
Square body, slotted center bolted tags
