Bussmann 170M-735 High-Speed gR Fuse-Link, NH1 Size, 800V AC

Bussmann 170M-735 High-Speed gR Fuse-Link, NH1 Size, 800V AC

(No reviews yet) Write a Review

Model: 170M7355

In Stock (leaves warehouse same day if ordered before 3pm ET)

$795.08
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M-735 High-Speed gR Fuse-Link, NH1 Size, 800V AC

The Bussmann 170M-735 is a high-speed gR fuse-link built to the IEC standard in the NH1 size, measuring 135 x 53 x 40 mm, with a dual combination fuse status indicator for at-a-glance condition checks. Rated 800V AC with a 65 kAIC interrupt rating, this family is available in amperage ratings from 80A to 400A (80A, 100A, 125A, 250A, 315A, 355A, and 400A) to match a wide range of semiconductor protection loads. It is UL Recognized and CE Marked for use in demanding industrial power distribution and semiconductor protection applications.

Key Features

  • NH1 Size: Fuse-link body measures 135 x 53 x 40 mm for standard NH1 fuse holders and disconnects.
  • Amperage Range: Available in 80A, 100A, 125A, 250A, 315A, 355A, and 400A ratings to match load and protection requirements.
  • Voltage Rating: Rated 800V AC for high-voltage industrial power distribution circuits.
  • Utilization Category: Class gR general purpose semiconductor protection for reliable coordination with semiconductor devices.
  • Interrupt Rating: 65 kAIC interrupt rating (65 kA breaking capacity and rated switching capacity) for high fault-current environments.
  • Dual Indicator: Combination fuse status indicator provides quick visual confirmation of fuse condition.
  • IEC Standard: Designed to IEC specifications for compatibility with international power distribution systems.

Certifications & Compliance

  • UL Recognized
  • CE Marked

Technical Specifications

  • Class: Class gR
  • Voltage Type: AC
  • Insulated Metal Gripping Lugs Imgl: No
  • Compliances: CE Marked
  • Utilization Category: gR (general purpose semiconductor protection)
  • Interrupt Rating: 65 kAIC
  • Certifications: UL Recognized
  • Breaking Capacity: 65 kA
  • Rated Switching Capacity: 65 kA
  • Fuse Indicator: Combination fuse status indicator
  • Voltage Rating: 800V

Typical Applications

  • Semiconductor Protection Circuits
  • Industrial Power Distribution Systems
  • Motor Drive and Rectifier Protection
  • Panelboard and Switchgear Installations
  • High Fault-Current Industrial Environments

Why Bussmann?

Bussmann fuse-links are engineered for dependable, code-compliant performance in demanding electrical environments. The 170M-735 combines a 65 kAIC interrupt rating, dual fuse status indication, and UL Recognized, CE Marked construction to deliver consistent semiconductor protection across its full 80A-400A range. This makes it a reliable choice for professionals specifying IEC-compliant, high-speed fuse protection.

Manufacturer Resources

Product Specs

Class:
Class gR
Voltage Type:
AC
Insulated Metal Gripping Lugs Imgl:
No
Compliances:
CE Marked
Utilization Category:
gR (general purpose semiconductor protection)
Interrupt Rating:
65 kAIC
Department:
Electrical
Certifications:
UL Recognized
Breaking Capacity:
65 kA
Rated Switching Capacity:
65 kA
Fuse Indicator:
Combination fuse status indicator
Voltage Rating:
800V
Product Type:
Fuse-Link
Grade:
gR
Amperage Rating:
80A - 400A
Listing:
UL Recognized
Standards:
CE Marked
Product Group:
Fuses
Product Subgroup:
Other Fuses
