Bussmann 170M2658 Class gR High-Speed Square Body Fuse, 25A, 700V/690V, 200 kAIC

Bussmann 170M2658 Class gR High-Speed Square Body Fuse, 25A, 700V/690V, 200 kAIC

(No reviews yet) Write a Review

Model: 170M2658

In Stock (leaves warehouse same day if ordered before 3pm ET)

$441.11
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M2658 Class gR High-Speed Square Body Fuse

The Bussmann 170M2658 is an Eaton Bussmann series high-speed square body fuse engineered for semiconductor protection, rated 700V (UL) and 690V (IEC) with a 25A rating and 200 kAIC interrupting capacity. Built to Class gR utilization category and DIN 43 620 dimensional standard, this fuse features a blade end x blade end connection with slotted offset bolted tags for secure termination. A top-mounted fuse status indicator provides quick visual confirmation of fuse condition, supporting fast troubleshooting in industrial power electronics circuits.

Key Features

  • Amperage & Voltage Rating: Rated 25A at 700V (UL) / 690V (IEC) AC for reliable overcurrent protection in demanding power electronics applications.
  • Interrupting Rating: 200 kAIC interrupting capacity delivers dependable fault current clearing for high-energy semiconductor circuits.
  • Class gR Utilization Category: Designed to general purpose semiconductor protection standards (Class gR) per DIN 43 620 dimensional specifications.
  • Blade End x Blade End Connection: Square body construction with slotted offset bolted tags for secure, low-resistance blade end x blade end termination.
  • Top Fuse Status Indicator: Integrated top-mounted status indicator allows quick visual verification of fuse condition without disconnecting the circuit.
  • Low Watt Losses: Rated at just 6W watt losses, minimizing heat generation and energy waste during continuous operation.
  • Compact Dimensions: Measures 66 mm (height) x 140 mm (width) x 233 mm (length) and weighs 221 g for straightforward panel integration.

Certifications & Compliance

  • IEC Rated
  • CE Marked

Technical Specifications

  • Amperage Rating: 25 A
  • Application: semiconductor protection
  • Certifications: IEC Rated
  • Clearing I2t: 130 at 660 V
  • Compliances: CE Marked
  • Fuse Shape: Square body, slotted offset bolted tags
  • Insulated Metal Gripping Lugs (IMGL): No
  • Packaging Type: Standard
  • Pre Arc I2t: 19
  • Product Height: 66 mm
  • Product Length Depth: 233 mm
  • Product Weight: 221 g
  • Product Width: 140 mm
  • Utilization Category: gR (general purpose semiconductor protection)
  • Voltage Rating: 690 V
  • Voltage Type: AC
  • Watt Losses: 6 W

Typical Applications

  • Semiconductor Device Protection
  • Power Electronics and Rectifier Circuits
  • Industrial Motor Drive Protection
  • High-Speed Fault Current Interruption

Why Bussmann?

Bussmann by Eaton is a trusted name in circuit protection, and the 170M2658 reflects that standard with CE marked, IEC rated construction built to DIN 43 620 dimensions for consistent fit and performance. Its Class gR square body design with slotted offset bolted tags and top-mounted status indicator delivers dependable, code-compliant protection for demanding semiconductor and power electronics installations.

Manufacturer Resources

Product Specs

Amperage Rating:
25 A
Application:
semiconductor protection
Certifications:
IEC Rated
Class:
Class gR
Clearing I2t:
130 at 660 V
Compliances:
CE Marked
Connection:
Blade end x blade end
Fuse Indicator:
Top fuse status indicator
Fuse Shape:
Square body, slotted offset bolted tags
Insulated Metal Gripping Lugs Imgl:
No
Interrupt Rating:
200 kAIC
Mounting Method:
DIN 43 620
Packaging Type:
Standard
Pre Arc I2t:
19
Product Height:
66 mm
Product Length Depth:
233 mm
Product Weight:
221 g
Product Width:
140 mm
Utilization Category:
gR (general purpose semiconductor protection)
Voltage Rating:
690 V
Voltage Type:
AC
Watt Losses:
6 W
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Other Fuses
Product Type:
Fuse
Product Details:
Fuse
