Bussmann 170M3216 High-Speed Square Body Fuse, 250A Class aR

(No reviews yet) Write a Review

Model: 170M3216

In Stock (leaves warehouse same day if ordered before 3pm ET)

$968.41
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M3216 High-Speed Square Body Fuse, 250A Class aR

The Bussmann 170M3216 is an Eaton Bussmann series high-speed square body fuse rated 1250V (IEC) / 1300V (UL) at 250A with a 200 kAIC interrupt rating, purpose-built for semiconductor protection. It features a Class aR utilization category, blade end x blade end terminals on a slotted, center-bolted square body, a top-mounted fuse status indicator, and conforms to the DIN 43 620 dimensional standard.

Key Features

  • Voltage Rating: 1250V (IEC) / 1300V (UL) for demanding power electronics and drive circuits.
  • Amperage Rating: 250A continuous current handling for high-power semiconductor protection.
  • Interrupt Rating: 200 kAIC breaking capacity for reliable clearing under high fault currents.
  • Class aR Utilization: accompanied semiconductor protection per the aR rating.
  • Terminal Configuration: blade end x blade end connections on a square body with slotted, center-bolted tags.
  • Fuse Status Indicator: top-mounted indicator provides at-a-glance fuse condition status.
  • Dimensional Standard: built to DIN 43 620 for square body fuse compatibility.

Certifications & Compliance

  • UL Recognized
  • CE Marked

Technical Specifications

  • Amperage Rating: 250 A
  • Application: semiconductor protection
  • Certifications: UL Recognized
  • Clearing I2t: 28500 at 660 V
  • Clearing Loss: 40
  • Compliances: CE Marked
  • Fuse Shape: Square body, slotted center bolted tags
  • Insulated Metal Gripping Lugs (IMGL): No
  • Packaging Type: Standard
  • Pre Arc I2t: 4200
  • Product Height: 65 mm
  • Product Length Depth: 305 mm
  • Product Weight: 342 g
  • Product Width: 145 mm
  • Utilization Category: aR (accompanied semiconductor protection)
  • Voltage Rating: 690 V
  • Voltage Type: AC

Typical Applications

  • Semiconductor Protection Circuits
  • Power Electronics and Drive Systems
  • High-Speed Fault Current Interruption
  • Industrial Motor Control and Power Conversion Equipment

Why Bussmann?

Bussmann fuses from Eaton are engineered for demanding semiconductor protection, combining a high 200 kAIC interrupt rating with Class aR clearing characteristics and a top-mounted status indicator for fast condition checks. UL Recognized and CE Marked compliance backs reliable, code-conscious performance for industrial power electronics.

Manufacturer Resources

Product Specs

Amperage Rating:
250 A
Application:
semiconductor protection
Certifications:
UL Recognized
Class:
Class aR
Clearing I2t:
28500 at 660 V
Clearing Loss:
40
Compliances:
CE Marked
Connection:
Blade end x blade end
Fuse Indicator:
Top fuse status indicator
Fuse Shape:
Square body, slotted center bolted tags
Insulated Metal Gripping Lugs Imgl:
No
Interrupt Rating:
200 kAIC
Mounting Method:
DIN 43 620
Packaging Type:
Standard
Pre Arc I2t:
4200
Product Height:
65 mm
Product Length Depth:
305 mm
Product Weight:
342 g
Product Width:
145 mm
Utilization Category:
aR (accompanied semiconductor protection)
Voltage Rating:
690 V
Voltage Type:
AC
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Other Fuses
Product Type:
Fuse
Product Details:
Fuse
