Bussmann 170M3515 High Speed Fuse

Bussmann 170M3515 200A Class aR High Speed Square Body Fuse

(No reviews yet) Write a Review

Model: 170M3515
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$773.05
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M3515 200A Class aR High Speed Square Body Fuse

The Bussmann 170M3515 is a 200A Class aR high speed square body fuse engineered for demanding DC power protection applications, including DC common bus systems, DC drives, and power converters/rectifiers. Rated at 1300 Vac (UL) and 1250 Vac (IEC) with a 200 kAIC interrupt rating, this fuse delivers dependable current-limiting protection for high-energy DC circuits carrying 200A RMS. It is IEC Rated and UL Recognized, helping ensure compliance with international and North American electrical standards for demanding DC power distribution equipment.

Key Features

  • Current Rating: 200A RMS for high-capacity DC circuit protection.
  • Fuse Class: Class aR high speed design engineered for fast-acting semiconductor and DC drive protection.
  • Voltage Rating: 1300 Vac (UL), 1250 Vac (IEC) for use across UL and IEC rated DC systems.
  • Interrupt Rating: 200 kAIC for dependable performance under high fault-current conditions.
  • Application: Designed for DC common bus, DC drives, and power converters/rectifiers.
  • Mounting Method: Flush mounting for compact panel and enclosure installations.
  • Fuse Indicator: Non indicating design.
  • Watt Losses: Rated at 35W for efficient thermal performance.

Certifications & Compliance

  • IEC Rated
  • UL Recognized
  • CE Marked
  • RoHS Compliant

Technical Specifications

  • Amperage Rating: 200A
  • Application: DC common bus, DC drives, power converters/rectifiers
  • Class: Class aR
  • Clearing I2t: Clearing at 660V: 15000
  • Current Rating: 200A RMS
  • Fuse Indicator: Non Indicating
  • Interrupt Rating: 200 kAIC
  • Packaging Type: Standard
  • Pre Arc I2t: 2200
  • Voltage Rating: 1300 Vac (UL), 1250 Vac (IEC)
  • Watt Losses: 35W
  • Product Type: Square body -G/- visual indicator
  • Product Length: 5.433 IN
  • Product Details: Square body -G/- visual indicator
  • Mounting Method: Flush
  • Product Height: 2.087 IN
  • Product Weight: 1.6456 LB
  • Product Width: .315 IN

Typical Applications

  • DC Common Bus Systems
  • DC Drive Protection
  • Power Converters and Rectifiers
  • Industrial DC Power Distribution
  • Semiconductor and High-Speed Fuse Protection

Why Bussmann?

Bussmann fuses are built for consistent, code-compliant performance in critical DC power applications. This Class aR high speed fuse combines a 200 kAIC interrupt rating with UL Recognized and IEC Rated compliance, plus CE marking and RoHS compliance, giving electrical professionals a dependable protection component for DC common bus, drive, and converter systems.

Manufacturer Resources

Product Specs

Amperage Rating:
200A
Application:
DC common bus, DC drives, power converters/rectifiers
Class:
Class aR
Clearing I2t:
Clearing at 660V: 15000
Current Rating:
200A RMS
Fuse Indicator:
Non Indicating
Interrupt Rating:
200 kAIC
Packaging Type:
Standard
Pre Arc I2t:
2200
Voltage Rating:
1300 Vac (UL), 1250 Vac (IEC)
Watt Losses:
35W
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Square Body Fuses
Product Type:
Square body -G/- visual indicator
Product Length:
5.433 IN
Product Details:
Square body -G/- visual indicator
Mounting Method:
Flush
Product Height:
2.087 IN
Product Weight:
1.6456 LB
Product Width:
.315 IN
