Bussmann 170M7065 Class aR Semiconductor Fuse, 3500A 690V

(No reviews yet) Write a Review

Model: 170M7065

In Stock (leaves warehouse same day if ordered before 3pm ET)

$7,056.08
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann 170M7065 Class aR Semiconductor Fuse, 3500A 690V

The Bussmann 170M7065 is a Class aR fuse engineered for semiconductor protection, rated 3500A at 690V AC with a 200 kAIC interrupt rating. Utilization category aR (accompanied semiconductor protection) suits high-fault-current circuits, and the design is UL Recognized and CE Marked for compliant installations. A top-mounted fuse status indicator delivers at-a-glance visual confirmation of fuse condition, and flush mounting supports standard panel installation.

Key Features

  • Amperage & Voltage: Rated 3500A at 690V AC for high-capacity semiconductor protection circuits.
  • Class aR Design: Utilization category aR (accompanied semiconductor protection) for coordinated circuit protection.
  • High Interrupt Rating: 200 kAIC interrupt rating supports demanding fault-current environments.
  • Fuse Status Indicator: Top fuse status indicator allows quick visual verification of fuse condition.
  • Mounting Method: Flush mounting for standard panel and enclosure installation.
  • Thermal Performance: Temperature rating greater than 60°C with watt losses of 325 W.

Certifications & Compliance

  • UL Recognized
  • CE Marked

Technical Specifications

  • Amperage Rating: 3500 A
  • Application: semiconductor protection
  • Certifications: UL Recognized
  • Class: Class aR
  • Clearing I2t: 22000000 at 660 V
  • Compliances: CE Marked
  • Fuse Indicator: Top fuse status indicator
  • Insulated Metal Gripping Lugs (IMGL): No
  • Interrupt Rating: 200 kAIC
  • Mounting Method: Flush
  • Packaging Type: Standard
  • Pre Arc I2t: 3250000
  • Temperature Rating: >60°C
  • Utilization Category: aR (accompanied semiconductor protection)
  • Voltage Rating: 690 V
  • Voltage Type: AC
  • Watt Losses: 325 W

Typical Applications

  • Semiconductor Device Protection
  • Variable Frequency Drives and Power Converters
  • Industrial Rectifier Circuits
  • High-Capacity Switchgear and Panelboards
  • Commercial and Industrial Electrical Installations

Why Bussmann?

Bussmann backs the 170M7065 with UL Recognized and CE Marked compliance, delivering dependable, code-compliant circuit protection for demanding environments. With a 200 kAIC interrupt rating and Class aR utilization category, this fuse provides the reliable semiconductor protection professional electrical installations require.

Manufacturer Resources

Product Specs

Amperage Rating:
3500 A
Application:
semiconductor protection
Certifications:
UL Recognized
Class:
Class aR
Clearing I2t:
22000000 at 660 V
Compliances:
CE Marked
Fuse Indicator:
Top fuse status indicator
Insulated Metal Gripping Lugs Imgl:
No
Interrupt Rating:
200 kAIC
Mounting Method:
Flush
Packaging Type:
Standard
Pre Arc I2t:
3250000
Product Height:
.001 mm
Product Length Depth:
.001 mm
Product Weight:
.001 g
Product Width:
.001 mm
Temperature Rating:
>60°C
Utilization Category:
aR (accompanied semiconductor protection)
Voltage Rating:
690 V
Voltage Type:
AC
Watt Losses:
325 W
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Other Fuses
Product Type:
Fuse
Product Details:
Fuse
