Bussmann 170M7107 2200A 1000V Class aR Semiconductor Fuse
The Bussmann 170M7107 is a Class aR semiconductor protection fuse rated 2200A at 1000V, engineered for demanding power electronics and power conversion equipment. This IEC-rated, CE marked fuse is documented with a 125 kAIC interrupt rating and manufacturer specification data listing 2400A at 1250V, supporting coordinated protection of solid-state devices in high-current industrial circuits. Configured for flush mounting with a 4SPKN/80PWAR body designation, it is built to safeguard thyristors, diodes, and IGBTs from short-circuit and overcurrent damage.
Key Features
- Amperage Rating: 2200A fuse body for high-current semiconductor protection applications.
- Voltage Rating: 1000V rating suited to high-voltage power conversion and drive circuits.
- Class aR Utilization Category: Accompanied semiconductor protection fuse (aR) per IEC classification, intended for use alongside a backup device.
- Interrupt Rating: 125 kAIC interrupt rating for reliable clearing of high fault currents.
- Flush Mounting: Configured for flush mounting in compatible fuse holders and disconnect assemblies.
- Let-Through Energy: Pre-arc I²t of 4,000,000 and clearing I²t of 25,000,000 at 1250V, supporting precise protection coordination.
- Power Loss: 255W watt-loss rating for accurate thermal design and enclosure planning.
- Type Designation: 4SPKN/80PWAR body and mounting configuration for correct holder fit.
Certifications & Compliance
- IEC Rated
- CE Marked
Technical Specifications
- Amperage Rating: 2400 A
- Application: semiconductor protection
- Certifications: IEC Rated
- Class: Class aR
- Clearing I²t: 25000000 at 1250 V
- Compliances: CE Marked
- Fuse Indicator: Other
- Insulated Metal Gripping Lugs (IMGL): No
- Interrupt Rating: 125 kAIC
- Mounting Method: Flush
- Packaging Type: Standard
- Pre Arc I²t: 4000000
- Product Height: 116 mm
- Product Length Depth: 202 mm
- Product Weight: 4975 g
- Product Width: 140 mm
- Utilization Category: aR (accompanied semiconductor protection)
- Voltage Rating: 1250 V
- Voltage Type: AC
- Watt Losses: 255 W
Typical Applications
- Semiconductor Device Protection (Thyristors, Diodes, IGBTs)
- Power Conversion and Rectifier Equipment
- Industrial Drive and Motor Control Systems
- High-Power Electronic Switching and Converter Circuits
