Bussmann BKCBC Type I Heavy-Duty Automotive Circuit Breaker

Bussmann BKCBC Type I Heavy-Duty Automotive Circuit Breaker

(No reviews yet) Write a Review

Model: BK/CBC-10

In Stock (leaves warehouse same day if ordered before 3pm ET)

$18.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann BKCBC Type I Heavy-Duty Automotive Circuit Breaker

The Bussmann BKCBC Type I heavy-duty automotive circuit breaker delivers reliable, manual-reset overcurrent protection for RVs, trucks, and marine electrical systems. Rated 14 Vdc with a 1.5 kAIC interrupt rating and a rugged #10-32 TPI stud connection, this circuit breaker is available in ratings from 10A to 50A to match a wide range of automotive and marine circuit protection needs. Its Type I, heavy-duty automotive construction is built to withstand the vibration, heat, and environmental demands of mobile electrical applications, making it a dependable choice wherever compact, resettable overcurrent protection is required in place of a traditional automotive fuse.

Key Features

  • Amp Rating Range: Available in ratings from 10A to 50A so installers can match the breaker to the specific circuit load.
  • Voltage Rating: 14 Vdc, engineered for automotive and marine electrical systems.
  • Interrupt Rating: 1.5 kAIC for dependable overcurrent interruption.
  • Connection: #10-32 TPI stud terminal for a secure, vibration-resistant connection.
  • Type I Heavy-Duty Design: Automotive, Type I, heavy-duty construction built for demanding mobile applications.
  • Manual Reset Protection: Functions as a resettable overcurrent device, reducing the need for spare fuses in the field.
  • Application: Purpose-built for RVs, trucks, and marine systems.
  • Packaging: Available in packaging quantities of 100 for stocking and distribution.

Technical Specifications

  • Interrupt Rating: 1.5 kAIC
  • Application: RVs , trucks and marine systems
  • Product Details: Automotive, type I, heavy duty
  • Connection: #10-32 TPI stud
  • Special Features: Packaging quantity 100
  • Item Quantity: Q6
  • Voltage Rating: 14 Vdc
  • Product Type: Automotive, type I, heavy duty
  • Product Weight: .5 LB

Typical Applications

  • RV Electrical Systems and Power Distribution
  • Truck and Commercial Vehicle Wiring
  • Marine Electrical Systems
  • Automotive Overcurrent Protection in Place of Fuses
  • Mobile and Off-Road Equipment Wiring

Why Bussmann?

Bussmann is a trusted name in circuit protection, and the BKCBC Type I heavy-duty circuit breaker reflects that standard with automotive-grade construction and a reliable #10-32 stud connection. Backed by a 1.5 kAIC interrupt rating and a broad 10A to 50A range, it gives RV, truck, and marine professionals a dependable, resettable alternative to standard automotive fuses for demanding mobile electrical systems where heat, vibration, and moisture are everyday realities.

Manufacturer Resources

Product Specs

Interrupt Rating:
1.5 kAIC
Application:
RVs , trucks and marine systems
Product Group:
Fuses
Product Details:
Automotive, type I, heavy duty
Connection:
#10-32 TPI stud
Special Features:
Packaging quantity 100
Item Quantity:
Q6
Voltage Rating:
14VDC
Department:
Electrical
Product Subgroup:
Automotive Fuses
Product Type:
Circuit Breaker
Product Weight:
.5 LB
Connection Type:
#10-32 Stud
Configuration:
Type I, Heavy Duty

Bussmann BK/CBC-10 – Frequently Asked Questions

1) Can I use the Bussmann BKCBC circuit breaker on a 12-volt RV or truck system?
Yes. The BKCBC is rated 14 Vdc, which is the standard nominal rating for 12-volt automotive, RV, truck and marine charging systems running at roughly 13.8 to 14.4 volts while the alternator is charging. It is a DC-only device, so do not put it on 24-volt equipment or on any AC branch circuit.
2) What amp ratings does the Bussmann BKCBC breaker come in?
The BKCBC family runs from 10A up to 50A. The two ordering points are the 10-amp BK/CBC-10 and the 50-amp BK/CBC-50B. Size the breaker to the wire and the load, not to the appliance's peak draw alone, since a Type I breaker cycles rather than staying open.
3) How does the BKCBC terminate - do I need ring terminals?
Termination is by #10-32 TPI stud, so the cables land on ring terminals sized for a #10 stud, secured with the stud nuts. There are no blade or push-on connections. The threaded stud is what keeps the joint tight under vibration in a truck or boat, but it also means you crimp and torque ring lugs rather than plugging in a spade.
4) What does Type I mean on this Bussmann automotive breaker, and will it reset itself?
Type I is the auto-reset style: the bimetal element opens on overcurrent and closes again once it cools, so the circuit cycles on and off while the fault is still present. That is what you want on a circuit you cannot afford to leave dead and cannot easily reach, and it is the opposite of a Type III manual-reset breaker with a push button. The BKCBC is built as an automotive, Type I, heavy duty device.
5) Is a 1.5 kAIC interrupt rating enough for a circuit fed straight off a battery?
1.5 kAIC is the fault current the BKCBC can safely interrupt. That covers branch and accessory circuits downstream of a main fuse or distribution block. It is not a main battery protection device: a large lead-acid or lithium bank can deliver fault currents well above that, so the main positive run off the battery should carry a high-interrupt fuse, with the BKCBC protecting the branches behind it.
6) Should I use a resettable breaker like the BKCBC instead of an automotive blade fuse?
Use the breaker where a blown fuse means a service call or a stranded vehicle. On lighting, pumps, winches and accessory circuits in RVs, trucks and marine systems, a resettable device clears a nuisance trip without anyone carrying spares. Stick with a blade fuse where the circuit is easy to reach, where you want a permanent open on a real fault, or where the spec calls for a specific fuse class.
7) Will the BKCBC hold up to vibration and heat in a mobile install?
It is built as a heavy-duty automotive Type I device for exactly that duty, and the #10-32 threaded stud terminals are a mechanical joint that does not shake loose the way a push-on connector can. Mount it where it is accessible and keep the lug nuts torqued at service intervals.
