Bussmann Eaton TPJ Series Telecommunication Fuse, 170V Non-Indicating

Bussmann Eaton TPJ Series Telecommunication Fuse, 170V Non-Indicating

(No reviews yet) Write a Review

Model: TPJ-100

In Stock (leaves warehouse same day if ordered before 3pm ET)

$727.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann Eaton TPJ Series Telecommunication Fuse, 170V Non-Indicating

The Bussmann Eaton TPJ Series Telecommunication Fuse is engineered by Eaton Bussmann to provide dependable overcurrent protection for telecommunication power distribution systems. Rated 170 Vac/dc, this fuse is suitable for both AC and DC circuit protection applications common in telecom power plants and central office equipment. Built with a glass melamine tube, the TPJ Series offers a non-indicating design for straightforward, reliable fuse replacement. The TPJ Series telecommunication fuse family is available across a full range of amp ratings, including 60A, 70A, 80A, 90A, 100A, 125A, and 150A, allowing electrical professionals to match the correct current rating to the specific telecom circuit being protected.

Key Features

  • Amp Rating Range: The TPJ Series is offered in 60A, 70A, 80A, 90A, 100A, 125A, and 150A ratings, giving installers flexibility to select the correct current protection level for a given telecommunication circuit.
  • Voltage Rating: Rated 170 Vac/dc, the TPJ Series telecommunication fuse is suitable for both alternating current and direct current telecom power distribution applications.
  • Durable Glass Melamine Tube Construction: The fuse body is constructed of a glass melamine tube, providing a rugged, stable housing designed for dependable, long-term fuse performance.
  • Non-Indicating Design: This TPJ Series fuse uses a standard non-indicating construction, providing straightforward overcurrent protection without a blown-fuse indicator window.
  • Eaton Bussmann TPJ Series: Part of the recognized Eaton Bussmann TPJ Series of telecommunication fuses, engineered specifically for telecom power protection applications.
  • Broad Application Range: With ratings spanning 60A through 150A, this fuse family supports a wide range of telecommunication equipment and power distribution circuit sizes.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Telecommunications Power Distribution Systems
  • Central Office and DC Power Plant Protection
  • Telecom Equipment and Rectifier Circuit Protection
  • Commercial and Industrial Electrical Installations
  • Panelboard and Power Distribution Circuit Protection

Why Bussmann?

Eaton Bussmann is a recognized name in circuit protection products, and the TPJ Series telecommunication fuse reflects that standard with its glass melamine tube construction and dependable non-indicating design. Offered in ratings from 60A to 150A at 170 Vac/dc, the TPJ Series gives electrical professionals a reliable option for protecting telecommunication power circuits. Choosing the Eaton Bussmann TPJ Series helps ensure code-compliant, dependable overcurrent protection for telecommunication power distribution applications.

Manufacturer Resources

Product Specs

Department:
Electrical
Product Type:
Fuse
Product Material:
Glass Melamine
Voltage Rating:
170V AC/DC
Amperage Rating:
60A-150A
Configuration:
Non-Indicating
Series:
TPJ
Product Group:
Fuses
Product Subgroup:
Other Fuses

Bussmann TPJ-100 – Frequently Asked Questions

1) Can a Bussmann TPJ fuse be used on a 48V DC telecom power plant?
Yes. The TPJ Series is rated 170 Vac/dc, so it protects both AC and DC circuits, and a 48V DC plant sits well inside that rating. It was built for telecom power distribution, central office and rectifier circuits. Order by amp rating: TPJ-60 through TPJ-150.
2) Does the TPJ fuse have a blown-fuse indicator?
No. The TPJ is the non-indicating version, so there is no indicator pin or window to show it has opened. You verify it with a meter or by continuity check. If your distribution panel relies on a visual or alarm-triggering indicator, the TPJ is the wrong choice and you want an indicating telecom fuse instead.
3) I need to replace a blown fuse in a telecom DC panel - how do I pick the right TPJ part number?
Match the amp rating stamped on the fuse you pulled, then order the matching part: a 100A becomes TPJ-100, a 125A becomes TPJ-125. Do not upsize to get more headroom, because the fuse is sized to protect the downstream conductor and equipment. Confirm the existing fuse is a non-indicating type, since the TPJ has no indicator, and that the panel voltage is at or under 170 Vac/dc.
4) Is the Bussmann TPJ a standard Class J fuse I can drop into a 600V industrial fuse block?
No. Despite the TPJ name, this is a telecommunication fuse rated 170 Vac/dc, not a 600V branch circuit fuse. Using it on a 480V or 600V industrial feeder would exceed its voltage rating. Keep the TPJ to telecom power distribution, central office DC plants and rectifier circuits.
5) What amp ratings does the Bussmann TPJ telecom fuse come in?
Seven ratings: 60A, 70A, 80A, 90A, 100A, 125A and 150A, ordered as TPJ-60, TPJ-70, TPJ-80, TPJ-90, TPJ-100, TPJ-125 and TPJ-150. Nothing below 60A or above 150A in this series, so if your circuit calls for a smaller fuse you need a different Bussmann telecom series.
6) What is the TPJ fuse body made of and does it hold up in a hot equipment room?
The body is a glass melamine tube. It is a rigid thermoset housing rather than a plastic or paper shell, which is why Bussmann uses it on telecom power fuses that live in continuously loaded DC distribution cabinets.
7) Can I stock one TPJ fuse for a whole central office, or do I need several sizes?
You need several. Each TPJ is a single fixed amp rating, so a facility running mixed rectifier and distribution circuits typically carries spares across the range, commonly 60A, 100A and 150A. Buying by rating is the only way to keep the protection matched to each circuit.
