Bussmann GBA Series Fast-Acting Ferrule Fuse, 1A-15A

Bussmann GBA Series Fast-Acting Ferrule Fuse, 1A-15A

(No reviews yet) Write a Review

Model: GBA-1-1/2

In Stock (leaves warehouse same day if ordered before 3pm ET)

$56.24
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann GBA Series Fast-Acting Ferrule Fuse, 1A-15A

The Bussmann GBA Series fast-acting fuse from Eaton Bussmann delivers dependable overcurrent protection for control circuits and electronic circuits. Built with a ferrule end x ferrule end connection for simple, secure in-line mounting, this fast-acting fuse series is available in ratings spanning 1A to 15A, including 1A, 1.5A, 2A, 3A, 4A, 5A, 8A, 10A, and 15A options, so electrical professionals can match the exact protection level a circuit requires. Each fuse ships in standard packaging with an item quantity of 100 units per package, making the GBA Series a practical choice for maintenance stock, panel builders, and OEM production runs that depend on consistent, code-aware fuse protection.

Key Features

  • Connection Type: Ferrule end x ferrule end design for secure, low-profile seating in compatible fuse holders and blocks.
  • Amp Rating Range: Offered from 1A up to 15A, with 1A, 1.5A, 2A, 3A, 4A, 5A, 8A, 10A, and 15A options covering a wide span of control and electronic circuit loads.
  • Fast-Acting Element: Fast-acting fuse construction opens quickly under overcurrent conditions to help safeguard sensitive control and electronic components.
  • Compact Body Size: .25 IN length by .25 IN width by 1.25 IN height footprint for tight panel layouts and equipment enclosures.
  • Application-Ready: Purpose-built for control circuits and electronic circuits where dependable low-current protection is required.
  • Standard Packaging: Supplied in standard packaging with an item quantity of 100 fuses per package for maintenance stock and OEM builds.

Technical Specifications

  • Connection: Ferrule end X ferrule end.
  • Packaging Type: Standard.
  • Application: Control circuits, electronic circuits.
  • Product Length: .25 IN.
  • Product Details: Pin indicating.
  • Fuse Indicator: Non Indicating.
  • Item Quantity: 100.
  • Product Weight: .86 LB.
  • Product Type: Pin indicating.
  • Product Width: .25 IN.
  • Product Height: 1.25 IN.

Typical Applications

  • Control Circuit Overcurrent Protection
  • Electronic Circuit Overcurrent Protection
  • OEM Equipment Manufacturing
  • Control Panel and Cabinet Wiring
  • Maintenance and Replacement Fuse Stock

Why Bussmann?

Bussmann by Eaton is a recognized name in circuit protection, and the GBA Series fast-acting fuse reflects that standard with a dependable ferrule end x ferrule end design built specifically for control circuit and electronic circuit applications. With ratings spanning 1A through 15A supplied in standard packaging with an item quantity of 100 units, the GBA Series gives electrical professionals and OEM builders a consistent, dependable option for low-current overcurrent protection across control panels, machine builds, and maintenance programs.

Manufacturer Resources

Product Specs

Connection:
Ferrule end X ferrule end
Packaging Type:
Standard
Application:
Control circuits, electronic circuits
Department:
Electrical
Product Length:
.25 IN
Product Group:
Fuses
Product Details:
Pin indicating
Fuse Indicator:
Non Indicating
Item Quantity:
100
Product Weight:
.86 LB
Product Type:
Fuse
Product Width:
.25 IN
Product Subgroup:
Other Fuses
Product Height:
1.25 IN
Connection Type:
Ferrule
Amperage Rating:
1A - 15A
Series:
GBA

Bussmann GBA-1-1/2 – Frequently Asked Questions

1) What amp ratings does the Bussmann GBA fuse come in?
The GBA Series covers 1A through 15A, and the individual ratings you can order are 1A (GBA-1), 1.5A (GBA-1-1/2), 2A, 3A, 4A, 5A, 8A, 10A and 15A. There is no 6A or 12A in the line, so if your control schematic calls for one of those, size to the next rating that suits the circuit rather than assuming a part number exists.
2) Will a Bussmann GBA fuse fit a standard 1/4 x 1-1/4 inch fuse holder?
Yes. The GBA body measures .25 IN by .25 IN by 1.25 IN, which is the common 1/4 inch diameter by 1-1/4 inch long ferrule size, and it uses a ferrule end by ferrule end connection. That drops into standard clip-style holders, in-line holders and fuse blocks built for that size.
3) Is the GBA a fast-acting fuse or a time-delay fuse, and which do I want for a control panel?
GBA is fast acting. The element opens quickly on an overcurrent, which is what you want ahead of electronic boards, relays and control wiring where a sustained fault would cook the components. If the circuit feeds a motor, transformer or anything with a heavy inrush at startup, a fast-acting fuse will nuisance-open on you and a time-delay fuse is the right call instead.
4) How many fuses come in a package of Bussmann GBA?
GBA fuses are supplied in standard packaging at 100 pieces per package. That is a carton quantity, not a single fuse, so it suits panel shops, OEM production runs and MRO shelf stock more than a one-off replacement. The package weight is listed at .86 LB.
5) Can I tell by looking whether a GBA fuse has blown?
Not from a visual indicator built into the fuse. The GBA is listed as non-indicating, so there is no pop-out pin or lamp to flag an open element. Troubleshooting means pulling the fuse and checking continuity with a meter, or using a holder with its own blown-fuse indication.
6) Is the Bussmann GBA suitable for branch circuit protection in a panelboard?
No. GBA is a supplementary-type small ferrule fuse intended for control circuits and electronic circuits, not for protecting a feeder or branch circuit. Branch circuit protection calls for a listed branch circuit fuse class or a breaker sized to the conductor. Use GBA downstream, on the control transformer secondary or on device-level electronics.
7) What is a good stocking spread of GBA fuses for a maintenance cabinet?
Because each GBA part number is a single amp rating, a maintenance program usually carries several. The nine ratings available are 1A, 1.5A, 2A, 3A, 4A, 5A, 8A, 10A and 15A, ordered as GBA-1 through GBA-15. The low end (1A to 5A) covers most electronic and instrumentation circuits, while 8A, 10A and 15A cover heavier control wiring. All share the same ferrule end by ferrule end body, so one holder type accepts the whole range.
