Bussmann KRP-C Low-Peak Class L Time-Delay Fuse

Bussmann KRP-C Low-Peak Class L Time-Delay Fuse

The Bussmann KRP-C Low-Peak Series is a family of current-limiting, time-delay Class L fuses engineered for demanding industrial and commercial power distribution systems, available in amperage ratings from 1600A to 2000A. Every fuse in this family carries a dual voltage rating of 600Vac and 300Vdc, giving electrical contractors, panel builders, and engineers a dependable option for both AC and DC power distribution applications. Each KRP-C Low-Peak fuse features bolted blade end x bolted blade end terminations for secure, low-resistance connections in large-amperage circuits, and delivers a high interrupt rating — up to 300 kAIC at 600Vac and 100 kAIC at Vdc — making the series well suited for protecting equipment and conductors in systems with high available fault current. As current-limiting, time-delay devices, KRP-C Low-Peak fuses reduce peak let-through current and energy during a short circuit while tolerating momentary overloads and inrush currents typical of large motor, transformer, and feeder circuits. This Low-Peak Class L family is commonly specified for service entrance, feeder, and switchgear protection where high interrupt capacity and dependable performance are required, regardless of which amperage rating in the 1600A-2000A range is selected.

Key Features

• Amperage Range: Available in ratings from 1600A to 2000A to support high-capacity overcurrent protection for large feeder and service entrance circuits.
• Dual Voltage Rating: 600Vac and 300Vdc rating allows every fuse in this family to be applied in both AC and DC power distribution systems.
• Current-Limiting, Time-Delay Operation: Limits peak let-through current and energy during short-circuit events while allowing for momentary overloads and inrush currents from motors and transformers.
• High Interrupt Rating: Up to 300 kAIC at 600Vac and 100 kAIC at Vdc, delivering dependable protection in systems with high available fault current.
• Class L Fuse: Conforms to Class L dimensional and mounting standards for compatibility with Class L fuse blocks, disconnects, and switchgear.
• Bolted Blade End x Bolted Blade End Termination: Secure, low-resistance bolted connections at both ends for reliable, high-amperage electrical continuity across the amperage range.
• Low-Peak Series Design: Part of the Eaton Bussmann Low-Peak family of current-limiting fuses engineered for demanding industrial applications.

Technical Specifications

• Voltage Rating: 600Vac / 300Vdc
• Interrupt Rating: 300 kiloamps
• Product Details: Current Limiting
• Select the specific amperage rating (1600A or 2000A) needed for your application when ordering.

Typical Applications

• Industrial Power Distribution Systems
• Motor Control Centers and Large Motor Circuits
• Switchgear and Panelboard Overcurrent Protection
• Service Entrance and Feeder Circuit Protection
• Facilities with High Available Fault Current
• Commercial and Industrial Equipment Protection

Why Bussmann?

Bussmann by Eaton is a widely specified name in overcurrent protection, and the KRP-C Low-Peak Series is engineered to deliver dependable current-limiting, time-delay performance in a standardized Class L form factor across its full 1600A-2000A range. With a dual 600Vac/300Vdc voltage rating and interrupt ratings up to 300 kAIC at 600Vac and 100 kAIC at Vdc, this fuse family is built for demanding applications where reliable overcurrent protection and code-compliant performance are essential. The bolted blade end x bolted blade end termination design supports secure installation in high-amperage panelboards, switchgear, and service entrance equipment where consistent, long-term electrical performance is required.
