Bussmann MDQ Series Dual-Element Time-Delay Fuse, Ferrule Terminals
Model: BUS-MDQ
Bussmann
Bussmann MDQ-V Series Time-Delay Fuse, Dual-Element Glass Tube
The Bussmann MDQ-V Series is a dual-element, time-delay fuse engineered for electronic relay and control circuit protection. Built with a glass tube body and nickel-plated brass endcaps, this ferrule end x ferrule end fuse is designed for use with axial leads and caps in electronic small-dimension applications. The MDQ-V Series is available in amp ratings from 1A through 10A (1A, 2.5A, 3A, 5A, 10A), with a non-indicating design and a response time of 60 minutes maximum at 135% and 120 seconds maximum at 200% overload.
Key Features
- Amp Rating Range: Available in 1A, 2.5A, 3A, 5A, and 10A ratings to match electronic relay and control circuit protection requirements.
- Dual-Element Design: Dual-element construction delivers reliable time-delay performance for inrush-tolerant circuit protection.
- Durable Construction: Glass tube body with nickel-plated brass endcaps resists corrosion and supports consistent long-term performance.
- Ferrule End Connection: Ferrule end x ferrule end termination is compatible with axial leads and caps.
- Non-Indicating: Fuse indicator type is non-indicating for standard circuit protection applications.
- Response Time: Rated 60 minutes maximum at 135% and 120 seconds maximum at 200% overload for predictable time-delay protection.
- Compact Dimensions: Measures 1.25 IN long, 1.25 IN high, and .25 IN wide, weighing .1 LB - sized for electronic small-dimension applications.
Technical Specifications
- Product Details: Electronic- small dimension
- Fuse Indicator: Non Indicating
- Response Time: 60 min maximum at 135%, 120 s maximum at 200%
- Number Of Elements: Dual
- Product Length: 1.25 IN
- Material Type: Glass tube with nickel-plated brass endcaps
- Connection: Ferrule end X ferrule end
- Product Weight: .1 LB
- Product Type: Electronic- small dimension
- Product Height: 1.25 IN
- Packaging Type: Standard
- Application: Electronic relay and control circuits
- Used With: axial leads and caps
- Product Width: .25 IN
Typical Applications
- Electronic Relay and Control Circuits
- Circuits Using Axial-Lead and Cap Components
- Electronic Small-Dimension Device Protection
- OEM Electronic Assemblies
Why Bussmann?
Bussmann is a recognized name in circuit protection, and the MDQ-V Series time-delay fuse reflects that standard with a glass tube body and nickel-plated brass endcap construction built for dependable performance. The dual-element design and defined response time characteristics make it a dependable choice for electronic relay and control circuit protection where consistent, code-compliant performance matters.
